Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: April 27, 2022 3:01 PM

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Product IDs

SHELF-2U-14-CENTER-V

SHELF-2U-20-CENTER-V

Product Diagram

Front - Angled View

ComponentFunction

1Shelf Lip

• Mount the with the 2U Vented Center-Mount Shelf

Shelf LipEquipment oriented upwards to prevent

from slipping o

2Mounting Holes (x 8)• Mount the into a 2U Vented Center-Mount Shelf

Rack.

Product Information

For the latest manuals, product information, technical specications, and declarations

of conformance, please visit:

www.StarTech.com/SHELF-2U-14-CENTER-V

www.StarTech.com/SHELF-2U-20-CENTER-V

Requirements

• 2U Available Rack Space

• Phillips Head Screwdriver

• (Optional) Cage Nut Tool

2U Vented Center-Mount Shelf - 14/20 in. Depth

Warnings

• Read the entire manual and ensure the instructions are fully understood before

assembling and/or using this product.

• Before adding equipment to this product, ensure this product has been properly

mounted.

• Ensure the weight of the equipment does not exceed the weight capacity of this

product. If the weight capacity is exceeded, personal injury or damage to the

equipment are possibilities. This product can support the following weight: up to

200.6 lb. (91 kg). This product can only support the maximum weight capacity if 8

M6 Screws / Cage Nuts / Plastic Washers are used to ax this product to a rack.

Package Contents

• 2U Vented Center-Mount Shelf x 1

• M6 Cage Nuts x 10

• M6 Screws x 10

• M6 Plastic Washers x 10

• Quick-Start Guide x 1

Installation

Mount the 2U Vented Center-Mount Shelf into a Rack

Use the included , w, and to install the M6 Cage NutsM6 ScresM6 Plastic Washers2U

Vented Center-Mount Shelf.

Notes: This product can support the following weight: .200.6 lb. (91 kg)

The following installation instructions are for square mounting holes.

1. Locate a suitable location in a to mount the . Rack2U Vented Center-Mount Shelf

Note: The itself requires of space within a 2U Vented Center-Mount Shelf2U Rack.

2. Insert the (side) of an into the back of the a .WingM6 Cage NutCage Nut Hole

3. Insert the second of the into the selected , using WingM6 Cage NutCage Nut Hole

pressure by hand, or with a .Cage Nut Tool

4. Repeat steps 2 and 3 to insert a total of 8 . Cage Nuts

5. Thread an over an . Repeat until 8 M6 Plastic WasherM6 ScrewM6 Screw

Assemblies have been prepared.
