Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: April 27, 2022 3:01 PM
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product IDs
SHELF-2U-14-CENTER-V
SHELF-2U-20-CENTER-V
Product Diagram
Front - Angled View
Component Function
1Shelf Lip
• Mount the with the 2U Vented Center-Mount Shelf
Shelf Lip Equipment oriented upwards to prevent
from slipping o
2Mounting Holes (x 8) • Mount the into a 2U Vented Center-Mount Shelf
Rack.
Product Information
For the latest manuals, product information, technical specications, and declarations
of conformance, please visit:
www.StarTech.com/SHELF-2U-14-CENTER-V
www.StarTech.com/SHELF-2U-20-CENTER-V
Requirements
• 2U Available Rack Space
• Phillips Head Screwdriver
• (Optional) Cage Nut Tool
2U Vented Center-Mount Shelf - 14/20 in. Depth
Warnings
• Read the entire manual and ensure the instructions are fully understood before
assembling and/or using this product.
• Before adding equipment to this product, ensure this product has been properly
mounted.
• Ensure the weight of the equipment does not exceed the weight capacity of this
product. If the weight capacity is exceeded, personal injury or damage to the
equipment are possibilities. This product can support the following weight: up to
200.6 lb. (91 kg). This product can only support the maximum weight capacity if 8
M6 Screws / Cage Nuts / Plastic Washers are used to ax this product to a rack.
Package Contents
• 2U Vented Center-Mount Shelf x 1
• M6 Cage Nuts x 10
• M6 Screws x 10
• M6 Plastic Washers x 10
• Quick-Start Guide x 1
Installation
Mount the 2U Vented Center-Mount Shelf into a Rack
Use the included , w , and to install the M6 Cage Nuts M6 Scre s M6 Plastic Washers 2U
Vented Center-Mount Shelf.
Notes: This product can support the following weight: .200.6 lb. (91 kg)
The following installation instructions are for square mounting holes.
1. Locate a suitable location in a to mount the . Rack 2U Vented Center-Mount Shelf
Note: The itself requires of space within a 2U Vented Center-Mount Shelf 2U Rack.
2. Insert the (side) of an into the back of the a .Wing M6 Cage Nut Cage Nut Hole
3. Insert the second of the into the selected , using Wing M6 Cage Nut Cage Nut Hole
pressure by hand, or with a .Cage Nut Tool
4. Repeat steps 2 and 3 to insert a total of 8 . Cage Nuts
5. Thread an over an . Repeat until 8 M6 Plastic Washer M6 Screw M6 Screw
Assemblies have been prepared.
1
*Product may vary from image
2
