Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: March 19, 2020 2:10 PM

Product Diagram (US2GA30)

Port/LEDFunction

1RJ45 Port• Used to connect to a Network Device.

2LED

• Solid Blue: Indicates that the CAT5/6/6a Cable

is connected to the RJ45 Port with a link speed

of 2.5Gbps.

• Solid Green: Indicates that the CAT5/6/6a

Cable is linked to the RJ45 Port with a link

speed of 1Gbps/100Mbps/10Mbps.

• Flashing LED: Indicates network activity.

• O: Indicates no connection.

3USB-A Connector

• Used to connect the Network Adapter to the

Host Computer.

Requirements

For the latest requirements, please visit www.startech.com/US2GA30.

USB-A™ 2.5Gb NBase-T Network Adapter

Installation

Hardware Installation

1. Connect a CAT5/6/6a Cable to the RJ45 Port on the Network Adapter and to a

Network Device.

2. Connect the USB-A Connector on the Network Adapter to a USB-A port on the

Host Computer.

Driver Installation

1. If the Drivers do not automatically download when you connect the Network

Adapter to the Host Computer, a message that a Virtual CD is loaded will appear.

2. Click on the message, the CD Drive screen will open.

CD Drive screen

3. Click on the folder that is compatible with your Host Computer and run the RTK_

NIC_DRIVER_INSTALLER le to begin the background installation.

1

3

2
