Instruction manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 06/11/2015

For the latest information, technical specications, and support for

this product, please visit www.startech.com/USB31000S2H.

Packaging contents

• 1 x USB 3.0 to Gigabit network adapter

• 1 x instruction manual

System requirements

• USB-enabled computer with an available USB 3.0 port

• Any of the following operating systems:

• Windows® 7 (32-bit or 64-bit)

• Windows 8 (32-bit or 64-bit)

• Windows 8.1 (32-bit or 64-bit)

• Windows Server® 2003

• Windows Server 2008

• Windows Server 2012

• Windows XP

• Windows Vista®

• Mac OS 10.7 and later (tested up to Mac OS 10.10)

• Linux® kernel 3.x

Operating system requirements are subject to change. For the latest

requirements, please visit .www.startech.com/USB31000S2H

USB31000S2H

USB 3.0 to Gigabit network adapter with built-in 2-port USB hub

*actual product may vary from photos

Product diagram

RJ-45 Ethernet port

USB Type-A

USB 3.0 ports

About USB 3.0 and USB 3.1 Gen 1

USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard

oers speeds up to 5 Gbps.

Installation

Install the network adapter

1. Turn on the computer that you’re connecting the network adapter

to.

2. Use an RJ-45 Ethernet cable to connect the network adapter to

your computer.

3. Connect the network adapter to an available USB port.

Note: If you connect to a USB 2.0 port, performance may be limited.

Install the driver on a computer running Windows

1. If the Found New Hardware dialog box appears on your screen,

close the dialog box or click Cancel.

2. An executable le will load, which you can use to install the driver.

Follow the on-screen instructions to complete the installation.

Note: If the driver for the network adapter doesn’t install

automatically, you need to manually install the driver. For more

information, see the instructions below.

Manually install the driver

1. To download the latest driver, navigate to www.startech.com and

enter in the search eld.USB31000S2H

2. Click the tab.Support

3. Download the driver.

4. When the download is complete, extract the contents of the

compressed le that you downloaded.

5. Double-click the appropriate driver for the version of the OS that

you’re running and follow the on-screen instructions to complete

the installation.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the

equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not

allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Produktspecifikationer

Varumärke:	StarTech.com
Kategori:	Nätverkskort/adapter
Modell:	USB31000S2H
Vikt:	25.9 g
Bredd:	37 mm
Djup:	255 mm
Höjd:	17 mm
Förpackningens bredd:	128 mm
Gränssnitt:	Ethernet
Kabelteknik:	10/100/1000BaseT(X)
Medeltid mellan fel (MTBF):	637901 h
Värdgränssnitt:	USB
Maximal dataöverföringshastighet:	5000 Mbit/s
Serveroperativsystem som stöds:	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019
Full duplex:	Ja
Produktens färg:	Svart
bruksanvisning:	Ja
Låddjup:	220 mm
Vikt inkl. förpackning:	106 g
Ytterförpackningens höjd:	270 mm
Produkter per ytterförpackning:	200 styck
Ytterförpackningens längd:	455 mm
Ytterförpackningens bredd:	355 mm
Andra operativsystem som stöds:	ChromeOS
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 70 ° C
Temperaturintervall (förvaring):	-10 - 55 ° C
Intervall för relativ operativ luftfuktighet:	40 - 50 %
Hållbarhetscertifiering:	CE, RoHS
Material, hölje:	Plast
USB-ström:	Ja
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
Automatisk MDIX IEEE:	Ja
Wake-on-LAN förberedd:	Ja
Kommunikationsstandarder:	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Linux operativsystem som stöds:	Ja
Harmonized System (HS)-kod:	85176990
Intern:	Nej
Kretsar:	Realtek RTL8153
Jumboramar:	9000
Jumbo Frames stöd:	Ja
Flödeskontroll:	Ja
VLAN-märkning:	Ja
Strömförbrukning:	1092 mA
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ A-hubbportar:	2
