X7DVA-8

USER’S MANUAL

Revision 1.1b

SUPER

X7DVA-E

Manual Revision: Rev. 1.1b

Release Date: Dec. 23, 2008

Unless you request and receive written permission from Super Micro Computer, INC., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. reserves the right to make changes to the product described in this

manual at any time and without notice. This product, including software, if any, and documentation

may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any

medium or machine without prior written consent.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	moderkort
Modell:	X7DVA-E ServerBoard
Bredd:	305 mm
Djup:	254 mm
Maximalt internminne:	24 GB
Kompatibla operativsystem:	64-bit/32-bit
Expansionsplatser:	1 x 200-pin IPMI slot (SIMLP)
Antal minnesplatser:	6
processortillverkare:	Intel
Nätverksegenskaper:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	2
Temperatur vid drift:	10 - 35 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	8 - 90 %
Fuktighet (förvaring):	5 - 95 %
processorsockel:	LGA 771 (Socket J)
Seriella portar:	1
Antal PS/2-portar:	2
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,10
Max antal processorer:	2
USB 2.0 anslutning:	2
Antalet Seriella ATA anslutningar:	6
BIOS minnesstorlek:	64 mbit
LAN-styrenhet:	Intel® 82563EB
Moderkortets chipset:	Intel® 5000V
Moderkort formfaktor:	ATX
Medföljande programvara:	- Super Doctor III\n- Watch Dog\n- NMI
Kvalitet på VGA (D-Sub) porten:	1
Antal anslutningar för fläktar:	6
Chassits genomgångsanslutning:	Ja
Maximalt minne på grafikkort:	16 MB
PCI-kortplatser:	1
Kontroll, gränssnitt:	Intel ESB2 SATA
Antalet parallella ATA-anslutningar:	1
Anslutning för diskettenhet:	Ja
PCI Express x4 platser:	1
Stödda kapaciteter hos minnesmodul:	1GB, 2GB, 4GB
Grafikkontroller:	ATI ES1000
PCI Express x8 kortplatser:	1
PCI-X-kortplatser:	2
