USER’S MANUAL

Revision 1.0a

X9DRG-HF

X9DRG-HTF

Manual Revision 1.0a

Release Date: May 20, 2013

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

and makes no commitment to update or to keep current the information in this manual, or to notify

any person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our Website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software and docu-

mentation, is the property of Supermicro and/or its licensors, and is supplied only under a license.

Any use or reproduction of this product is not allowed, except as expressly permitted by the terms

of said license.

IN NO EVENT WILL SUPER MICRO COMPUTER, INC. BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE

USE OR INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF

THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC.

SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between the manufacturer and the customer shall be governed by the laws of

Santa Clara County in the State of California, USA. The State of California, County of Santa Clara

shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for

all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class

A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instruction manual, may cause harmful

interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your

own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate

warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this

product may expose you to lead, a chemical known to

the State of California to cause birth defects and other

reproductive harm.

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	moderkort
Modell:	X9DRG-HTF
Bredd:	503 mm
Djup:	234 mm
Komponent för:	Server
Minnesspänning:	1.35, 1.5 V
Antal processorer som stöds:	2
Intel® Xeon-serien:	E5-2600
Minnestyper som stöds:	DDR3-SDRAM
BIOS-typ:	AMI
ACPI-version:	3.0
processortillverkare:	Intel
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	2
Temperatur vid drift:	10 - 35 ° C
Intervall för relativ operativ luftfuktighet:	8 - 90 %
processorsockel:	LGA 2011 (Socket R)
Hållbarhetscertifiering:	RoHS
Antal PS/2-portar:	1
Nätverksansluten (Ethernet):	Ja
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,5, 10
Minnets hastigheter:	800,1066,1333,1600 MHz
USB 2.0 anslutning:	2
BIOS minnesstorlek:	128 mbit
Moderkortets chipset:	Intel® C602
Kvalitet på VGA (D-Sub) porten:	1
PCI Express-kortplatser version:	2.0, 3.0
Ombord grafikkort modell:	Matrox G200eW
Lagringsenhetsgränssnitt som stöds:	SATA II, SATA III
Antal SATA III kontakter:	2
Antalet DIMM-platser:	8
Som stöds DIMM-modul kapacitet:	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
Stöd för UDIMM klockfrekvenser:	800,1066,1333,1600 MHz
Antal SATA II kontakter:	4
PCI Express x4 platser:	1
PCI Express x16 platser:	4
PCI Express x8 kortplatser:	1
Maximalt RDIMM minne:	256 GB
Maximalt UDIMM minne:	64 GB
Stöd för RDIMM klockfrekvenser:	800,1066,1333,1600 MHz
IPMI LAN (RJ-45)-port:	Ja
Stöds QPI:	8 GT/s
