Quick Installation

Guide

Whole Home Mesh Wi-Fi AP

Connect the Hardware

Connect the power adapter to the mesh device.

Connect the WAN/LAN port of the mesh device to your modem/router’s Ethernet port via an Ethernet cable.

Modem/Router Mesh Device Ports

Verify the status LED is ashing blue before continuing with the conguration.

The Whole Home Mesh Wi-Fi AP is designed to create a mesh wireless

network throughout your home.

Internet

Power Adapter

POWER WAN/LAN LAN1 LAN2 RESET

Set Up the Network

You can easily set up and manage your network through the Aginet app.

Search for Aginet on the Apple app Store or Google Play, or simply scan

the QR code below. Download and install the Aginet app.

1. Connect your Laptop/PC/Mobile phone to the mesh device

wirelessly or with an Ethernet cable.

2. Launch a web browser, and enter http://tplinkwi.net or

http://192.168.88.1 in the address bar. Create your own login

password and log in to the device.

3. Follow the Quick Setup instructions to set up your network.

Note:

1. If the login window does not appear, please refer to in this guide.Q1 Need Help? of

2. For ISP customized mesh devices, the login account name and password may be printed on the

product label.

Scan for Aginet Aginet

3. Set up your network

Note: This step is optional. If you don’t have an account, you may choose to create a TP-Link ID, or

simply manage your device without it. To enjoy a more complete service from TP-Link, bind your

TP-Link ID to the mesh device.

The default wireless network name (SSID) and password are printed on

the product label at the bottom of the mesh device.

How will you connect your device to

the internet?

Connect via Ethernet Cable

(to a Modem)

Method 2: Via a Web BrowserMethod 1: Via TP-Link Aginet App

1. Download the Aginet app.

2. Open the Aginet app and log in with your TP-Link ID.

Set Up the Network

Power: 12V 1.0A

SSID: TP-Link_XXXX

Wireless Password/PIN:XXXXXXXX

http://tplinkwi.net

High

Middle

Low

Save

Conrm Password

New Password

Select the device type you’d like to

add.

Mesh Device

After completing the conguration of the rst device, you can choose

to add more mesh devices to extend Wi-Fi coverage.

Tap "Create a Network" in the Aginet app then choose "Connect via

Ethernet Cable". Follow the steps to complete the setup and connect to

the internet.

Wi-Fi/

WPS

Reset

USB WN LAN1 LAN2 LAN3 LAN4

Note: For dierent mesh devices, the

ports may dier from actual products.

USB WAN LAN1 LAN2 LA

WAN

Produktspecifikationer

Varumärke:	TP Link
Kategori:	ej kategoriserat
Modell:	HX220
Produkttyp:	Mesh-router
Bredd:	100 mm
Djup:	100 mm
Höjd:	89.5 mm
Mobila operativsystem som stöds:	Android 4.4, iOS 9.0
LED-indikatorer:	Ja
Wi-Fi-standarder:	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Certifiering:	CE, FCC
Återställningsknapp:	Ja
Ethernet WAN:	Ja
Ethernet-kabel:	Ja
SSID-sändning:	Ja
Sändningseffekt (CE):	20 - 23 dBm
Sändningseffekt (FCC):	30 dBm
Produktens färg:	Vit
Antal LAN (RJ-45) anslutningar:	3
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-40 - 60 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	5 - 90 %
Antal produkter som medföljer:	1 styck
Föräldrakontroll:	Ja
Hållbarhetscertifiering:	CE
Kryptering/säkerhet:	WMM, WPA, WPA2, WPA3
AC-adapter inkluderad:	Ja
Kommunikationsstandarder:	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g
Stöd för garanterad tjänstekvalitet (QoS):	Ja
Wi-Fi-standard:	Wi-Fi 6 (802.11ax)
Wi-Fi-band:	Dual-band (2,4 GHz / 5 GHz)
Portvidarebefordran:	Ja
Dataöverföringshastighet via WLAN (första bandet):	574 Mbit/s
Dataöverföringshastighet via WLAN (andra bandet):	1201 Mbit/s
Brandväggssäkerhet:	SPI Firewall
Antal enheter som ingår:	1 styck
Strömstyrka in, AC-adapter:	1 A
Stöd till WAN typer:	Dynamic IP, Static IP, PPPoE
