Sida 1/59
TRT-BA-TAC-XT18-TAC-XT27-TC220209TTRT01-001-EN
TAC XT 18 / TAC XT 27
EN
ORIGINAL INSTRUCTIONS
VERTICAL HEATER
2 EN
vertical heater TAC XT 18 / TAC XT 27
Table of contents
Notes regarding the instructions ..........................................2
Safety .....................................................................................3
Information about the device................................................6
Transport and storage...........................................................8
Assembly and installation.....................................................8
Operation .............................................................................11
Available accessories..........................................................18
Errors and faults..................................................................19
Maintenance ........................................................................19
Technical annex...................................................................24
Disposal ...............................................................................58
Declaration of conformity ...................................................58
Notes regarding the instructions
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning of hot surface
This symbol indicates dangers to the life and health of
persons due to hot surface.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
instructions must be observed.
Wear foot protection
Information marked with this symbol indicates that you
should wear safety boots.
You can download the current version of the instructions via the
following link:
TAC XT 18
https://hub.trotec.com/?id=46248
TAC XT 27
https://hub.trotec.com/?id=46249
EN 3
vertical heater TAC XT 18 / TAC XT 27
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
Warning
Children of less than 3years should be kept away from
the device unless continuously supervised.
Children aged from 3years and less than 8years shall
only switch on/off the appliance provided that it has
been placed or installed in its intended normal
operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
Children aged from 3years and less than 8years shall
not plug in, regulate and clean the appliance or
perform user maintenance.
Warning
Do not use the device in small rooms if persons are
present who cannot leave the room independently and
who are not under constant supervision.
• Do not use the device in potentially explosive rooms and
do not install it there.
• Do not use the device in aggressive atmosphere.
• Do not use the device in atmospheres containing oil,
sulphur, chlorine or salt.
• This appliance is not a toy. Keep away from children and
animals. Do not leave the device unattended during
operation.
• Only put up the device in an upright, stable position on firm
ground.
• Make sure that the air inlet and outlet are not obstructed.
• Make sure that the suction side is kept free of dirt and
loose objects.
• Do not place the device on combustible ground.
• Never insert any objects or limbs into the device.
• Do not cover the device during operation.
• Do not use the device with wet or damp hands.
• Let the device dry out after a wet clean. Do not operate it
when wet.
• Do not expose the device to directly squirting water.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The mains connection must correspond to the
specifications in the Technical annex.
• Insert the mains plug into a properly fused mains socket.
• Observe the device's power input, cable length and
intended use when selecting extensions to the power
cable. Completely unroll extension cables. Avoid electrical
overload.
• Check the power cable and mains plug for damage. If you
notice damages, do not try to take the device back into
operation. Order a new power cable with mains plug from
Trotec and replace the defective power cable with mains
plug with the new one.
Defective power cables pose a serious health risk!
• Disconnect the device from the mains, if it is not in use.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not sit on the device.
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
annex.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Only use original spare parts, for otherwise safe and
functional operation cannot be ensured.
• Allow the device to cool down before transport and/or
maintenance work.
• Do not use this device near bathtubs, shower trays,
swimming pools or other water containers. Risk of electric
shock!
4 EN
vertical heater TAC XT 18 / TAC XT 27
Intended use
Only operate the device with atmospheric air.
Only use the device for the following:
• Decontamination (thermal virus inactivation and thermal
decontamination of respiratory masks, personal protective
equipment and entire rooms)
• HEPA filter air purification
• Thermal pest control
• Room heating
Use the device in accordance with the technical data.
Any other use is regarded as non-intended use and may be
dangerous. The observance of these instructions are also
considered part of the intended use.
Foreseeable misuse
Do not operate the device with an incorrect combination of
system components (e.g. for HEPA air purification without the
HEPA filter inserted).
Do not place any objects, e.g. clothing, on the device.
The device is not suitable for the use in explosive areas.
The device must not be used for sucking in fluids, e.g. from
filled tanks or basins.
Do not place the device on wet or flooded ground.
The device may not be exposed to moisture or weather effects
(rain, sunlight).
Any operation other than as described in this manual is
prohibited. Non-observance renders all claims for liability and
guarantee null and void.
Any unauthorised modifications, such as alterations or structural
changes to the device and changes and interventions in
software or firmware are forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric heaters.
• have read and understood the instructions, especially the
Safety chapter.
Maintenance tasks which require the housing to be opened
must only be carried out by specialist electrical companies or by
Trotec.
Instructed person
Instructed persons have been informed of the tasks they were
entrusted with as well as of potential hazards resulting from
inappropriate behaviour. They are allowed to operate and
transport the device and perform simple maintenance activities
(cleaning the housing, cleaning the fan).
The device is to be maintained and looked after by instructed
personnel.
Symbols on the device
Symbols Meaning
This symbol located on the device indicates that it
is prohibited to place objects (such as towels,
clothes etc.) above or directly in front of the
device.
In order to avoid overheating and fire hazards, the
heater must not be covered.
This symbol located on the device indicates that it
is prohibited to spray the device.
This symbol located on the device indicates
dangers to the life and health of persons due to
hot surface.
EN 5
vertical heater TAC XT 18 / TAC XT 27
Safety signs and labels on the device
Note
Do not remove any safety signs, stickers or labels from
the device. Keep all safety signs, stickers and labels in
legible condition.
The following safety signs and labels are attached to the device:
The following label is attached to the device in German and
English and French.
Safety warnings:
Caution! Risk of electric shock– do not open
No parts that need to be maintained are in the inside of the
device!
The following label is attached to the device in English.
Safety warnings:
Warning! Fire hazard.
Do not use in living spaces!
The following label is attached to the device in German, English,
French and Dutch.
Safety warnings:
Attention! Prior to switching the main switch off, wait for the
device to stop properly!
The following label is attached to the device in German.
Safety warnings:
Switch off the main switch prior to opening the housing!
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Do not touch the mains plug with wet or damp hands.
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning of hot surface
Parts of this appliance can become very hot and cause
burns. Particular attention is to be paid when there are
children or vulnerable persons present!
Warning of hot surface
The room temperature may increase up to75°C
during operation.
Note that the surfaces in the room may be hot after the
treatment.
Warning
The room temperature may increase up to75°C
during operation.
If possible, do not stay in the room during the room
heating process. If you feel unwell, exit the room
immediately. Persons sensitive to heat must only stay
in the room after the room has cooled down.
Remove objects and substances not suitable for these
temperatures from the room. Observe the
combustibility of the objects and substances in the
room.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
Improper installation entails a risk of fire.
Do not place the device on combustible ground.
Do not place the device on high-pile carpets.
6 EN
vertical heater TAC XT 18 / TAC XT 27
Warning
In order to avoid overheating and fire hazards, the
device must not be covered!
Note
Do not operate the device without an inserted air filter!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
Note
Only operate the device using the various application
programmes and with the corresponding system
components.
Make sure that a HEPA filter is inserted for HEPA air
purification.
Behaviour in the event of an emergency
1. Switch off the device at the main switch.
2. Secure the device against restart.
3. Make sure that neither you nor other persons access the
danger area.
4. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
5. Do not reconnect a defective device to the mains.
Only take the device back into operation once the emergency
has been resolved.
Information about the device
Device description
The device is designed to be a mobile solution for room frost
protection, comfort heating, pest control, surface
decontamination, HEPA filter operation and room
decontamination.
Each device comes equipped with the respective application
programmes which can be adjusted as needed. For example,
you can adapt the type of treatment, the duration and the target
temperature.
Variable equipment option: Depending on the application
purpose, you can use the system component combinations with
DualDecon blowing-out tower (standard) or TACXT18 /
TACXT27 with DualHeat blowing-out tower.
Application purpose Combination of system
components
DualDecon DualHeat
Thermal decontamination in target
room, including air purification
x
Thermal decontamination in target
room
x
Decontamination including air
purification via supply air from
installation in another room
x
Thermal decontamination via
supply air from installation in
another room
x
Pest control x x
HEPA filter air purification x
Central room heating with optional
air purification
x
Central room heating x x
Decentralised room heating via
existing ventilation systems or
textile air distributors
x x
Generally, the TACXT18 / TACXT27 is delivered with the
DualDecon blowing-out tower.
EN 7
vertical heater TAC XT 18 / TAC XT 27
Functioning principle
The air is taken in by the fan via the air inlet with air filter and
will be heated by means of the multi-stage electric heating.
Optionally, the heated air can be purified with a HEPA filter.
Afterwards, the air will be evenly distributed throughout the
room via the blowing-out tower. The device can also be
connected to a ventilation system using an attachment hood on
a hose connection.
For the purpose of pest control, no HEPA filter should be
installed on the device, so as to allow for a maximum air flow
rate.
If the device is operated with a ventilation system, the use of an
external thermostat (HG 125 - 6.100.002.042) is required.
The blowing-out temperature (identical to the supply
temperature) can be set up to maximally95°C. The
temperature sensors at the air inlet and the air outlet regulate
the adjusted room temperature within a narrow range as they
activate or disactivate additional individual heating elements.
Device depiction
1
2
3
7
8
9
10
4
6
5
No. Designation
1Blowing-out tower (DualDecon version depicted)
2Connections and main switch
3Wheel
4Power connection 2
5Power connection 1
6Transport handle
7Foot
8Air inlet with air filter
9Display and button
10 HEPA filter
8 EN
vertical heater TAC XT 18 / TAC XT 27
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
To make the device easier to transport, it is fitted with a
transport handle and two wheels.
Wear foot protection
Wear suitable foot protection transporting the device.
Risk of injury caused by the foot when setting down the
device.
Before transporting the device, observe the following:
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Only wheel the device on a level and smooth surface.
• Remove all packing materials which serve to protect the
device during transport.
• Should the device be damaged, please contact the
responsible dealer or manufacturer, where the purchase
was made.
• Carefully tilt the device. Do not incline more than
necessary.
• Carefully set the device back down again.
• The device may only be lifted at the points provided with
lifting gear intended for handling. The carrying capacity of
the lifting gear must be suitable for the weight of the
device (see technical data).
After transporting the device, proceed as follows:
• Set up the device in an upright position after transport.
Storage
When the device is not being used, observe the following
storage conditions:
• Store the device in a dry location and protected from frost
and heat.
• If required, use a cover to protect the device from invasive
dust.
• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
• Have the device checked once a year by an electrically
skilled person at any rate.
Assembly and installation
Scope of delivery
• 1x Device
• 1xDualDecon blowing-out tower
• 1 x Prefilter G4
• 1x Manual
Assembly
Installation of the blowing-out tower and insertion of the
HEPA filter (optional)
1. Using a screwdriver, remove the protective caps of
the4screws from the top of the device.
2. Remove all4screws.
3. Take off the blowing-out tower( ) from the device.1
1
4. Insert a HEPA filter( ) for the air purification mode.10
ðPest control requires a maximum air flow rate.
Therefore we recommend not using a HEPA filter for this
application.
ðThe HEPA filter(optional) may only be used with the
upper filter insert( ).11
10
11
5. Place the desired blowing-out tower( ) on the device.1
10 EN
vertical heater TAC XT 18 / TAC XT 27
8. Ensure that the pipe or tube and the hood are tightly
secured.
ðEnsure that the pipe or tube connected is heat-resistant.
Connection example:
13
Start-up
When positioning the device, observe the minimum distance
from walls or other objects as described in the chapter
Technical annex.
A
B
C
C
D
• Before restarting the device, check the condition of the
power cables. If there are doubts as to their sound
condition, contact the customer service.
• The device may only be used in environments with no
excessive formation of dust.
• Set the device up in an upright and stable position.
• Position the device on even, stable and heat-insensitive
ground in a way to prevent it from tipping over.
• When setting up the device, ensure a sufficient distance
for air inlet and outlet as well as for operation (see
Technical data).
• Do not create tripping hazards when laying the power
cables or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.
• Make sure that extension cables are completely unrolled.
• Make sure that no curtains or other objects interfere with
the air flow.
• Make sure that the device cannot come into contact with
moisture or water.
Inserting the air filter
Note
Do not operate the device without an air filter inserted
into the air inlet!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
• Make sure that the air filter is installed before switching
the device on.
Attaching a flowstop shutter
The optional flowstop shutters can be attached to one of the
four insides of the tower. This prevents up to three sides of the
tower from discharging air, e.g. if discharged air is not desired
or not required on the respective side(s).
Connecting the power cable
• The device is provided with two power cables. If you only
connect one power cable to the an power connection 1( ),5
the TACXT18 only supplies 9kW and the TACXT27
supplies 18kW. Connection of the second power cable to
power connection 2 ( ), the devices will supply their4
maximum power. The device can be operated with a
generator with sufficient capacity. Take into consideration
that the heat output of the device is controlled, so that the
generator connected has to adapt to the control. Ensure in
advance whether the generator complies with the power
supply of the device.
4
5
EN 11
vertical heater TAC XT 18 / TAC XT 27
Operation
Operating elements
14
15
20
19
16
17
18
No. Designation Meaning
14 Operating hours
counter
Indication of operating hours
15 Main switch Switching the device on or off
16 Fusing for safety
temperature limiter
Triggers in the event of
overheating
17 Touchscreen Selection of programmes and
adjustment of parameters
18 Start/stop key Starting or exiting the program
19 USB interface with
locking cap
Update of the control software via
USB flash drive with application
software
20 Thermostat connection
(hygrostat HG125)
• Temperature measurement
of other rooms when
connected to a ventilation
system
• If the thermostat is
connected, the room
thermostat inside the device
will be deactivated
12 EN
vertical heater TAC XT 18 / TAC XT 27
Switching the device on
1. Once you have completely installed the device as
described in the Start-up chapter, you can switch it on.
2. Turn the main switch( ) to .15 1
ðThe device is initialized.
ðPlease wait will be indicated on the display.
1234 123,4 123
123,4
please wait ?
14:29TAC XT
ðOnce the device has been initialised, the display
switches to standby mode.
3. Briefly touch the centre of the display.
ðThe main menu appears on the display.
Main menu
Off On
Setpoints
Configuration Back
4. If required, select the device function and carry out the
settings of the setpoints (see the following sections in the
“Operation” chapter).
5. Start the device or function by pressing the button.On
Enter the pass code
You might be requested to enter your pass code at initial start-
up.
The following screen will appear:
Factory settings
Enter pass code
reset
Factory settings
Activation Back
Please proceed as follows to enter the pass code:
1. Press the button.Enter pass code
2. Enter the pass code.
3. Press the button to confirm the entry.Accept
ðIf the pass code is incorrect is displayed. IfCode invalid
the entry is correct, it is saved.
Back
12345
Enter pass code
Confirm
Code invalid
4. Press the button to exit the pass code entry area.Back
Note
If you forget the PIN, you will not be able to unlock the
display. In this case you can request an emergency
unlock code via the TrotecGmbH service hotline
on+4902452962-730. The service hotline is
available Monday to Thursday from 8am to 5:30pm
and Friday until 5pm. You need the date and time
indicated on the display. You can view the information
by pressing the time button.
Language setting
1. Press the button in the main menu.Configuration
ðButtons for further settings will be indicated on the
display.
System
Configuration
Function selection
System settings
Back
2. Press the button.System settings
ðThe following screen is shown:
Back
System Vers. : 2.03.01
Factory settings
Language setting
Clock setting
Touch/Display
3. Press the button to select a language. Language selection
4. Use the arrow buttons to select the desired language.
5. Confirm the language selection by pressing the Confirm
button.
6. Press the button to exit the language settings.Back
EN 13
vertical heater TAC XT 18 / TAC XT 27
Setting the time
1. Press the following buttons in the main menu to set the
time:
ðConfiguration
ðSystem settings
ðClock setting
2. Use the arrow buttons to set the time.
ðThe settings are applied immediately.
3. Press the button to exit the time settings.Back
Display
1. Press the following buttons in the main menu to make
touchscreen settings:
ðConfiguration
ðSystem settings
ðTouch/display
2. Adjust the settings as desired:
ðContrast: Use the arrow buttons to set the contrast.
ðTouch beep on/off: Press the button to switch the touch
tone on or off.
3. Press the button to return to the main menu.Back
Device functions
The device comes with the following device functions:
• Room frost protection
• Comfort heating
• Pest control
• Surface decontamination
• HEPA filter operation
• Room decontamination
Room frost protection
The room frost protection function serves to keep a room free of
frost.
1. Press the following buttons in the main menu to carry out
settings regarding the room frost protection function:
ðConfiguration
ðConfiguration
ðRoom frost protection configuration
ðThe following screen will appear, allowing you to carry
out settings regarding the room frost protection
function:
Back
Room frost protection configuration
Fan control
Setpoints
2. Press the button.Setpoints
ðThe following screen is shown:
Back
Room frost protection setpoint
Room temperature
Outlet temperature
Configuration
6°C
50°C
3. Press the button on the Room temperature Room frost
protection setpoint screen.
4. Press the button to set the room°C specification
temperature on the next screen via the arrow buttons.
5. Press the button to return to the Back Room frost
protection setpoint screen.
6. Press the button on the Blowing-out temperature Room
frost protection setpoint screen.
7. Press the button to set the desired°C specification
blowing-out temperature on the next screen via the arrow
buttons.
8. Press the button on the Configuration Room frost
protection setpoint screen to save the settings.
9. Press the button to return to the Back Room frost
protection configuration screen.
10. Press the button.Fan control
ðThe following screen is shown:
Back
On/offDuration
Fan control
45 %
11. Press the or button on the Duration On/off Fan control
screen.
ðIf the button is activated, the device runs inDuration
continuous operation. To carry out this setting, press the
% specification Fan control button on the screen to
adjust the fan operating time via the arrow buttons on
the next screen. Press the button twice to return toBack
the screen.Room frost protection configuration
ðIf the button is activated, the fan switches offOn/off
automatically once the room temperature exceeds the
setpoint by 1°C. The fan is switched on again once the
room temperature drops below the setpoint by 1°C.
Press the button to return to the Back Room frost
protection configuration screen.
14 EN
vertical heater TAC XT 18 / TAC XT 27
Comfort heating
The comfort heating function is used for heating the room where
the device is installed, providing maximum user comfort, in
continuous operation or by means of an operating time
preselection in timer mode.
1. Press the following buttons in the main menu to carry out
settings regarding comfort heating:
ðConfiguration
ðConfiguration
ðComfort heating configuration
ðThe following screen will appear, allowing you to carry
out settings regarding the comfort heating function:
Back
Comfort heating configuration
Timer operation
Heating Fan control
Supply air limitation
Setpoints
2. Press the button.Setpoints
ðThe following screen is shown:
Back
25°C
33 %
Comfort heating setpoint
Outlet temperature
Fan
Configuration
3. Press the button on the Blowing-out temperature Comfort
heating setpoint screen.
4. Press the button to set the blowing-out°C specification
temperature on the next screen via the arrow buttons.
5. Press the s button in the Fan Comfort heating setpoint
screen.
6. Press the button to set the air volume flow% specification
in the next screen via the arrow buttons.
7. Press the button on the Configuration Comfort heating
setpoint screen to save the settings.
8. Press the button to return to the Back Comfort heating
configuration screen.
9. Press the button.Timer mode
10. Press the or button on the screen toOff On Timer mode
deactivate or activate the timer.
ðWhen the button is activated, the timer startsOn
running once the device is switched on. When the set
time has elapsed, the device switches off.
11. Press the button.Minutes
12. Press the arrow buttons on the screen toOperating time
set the operating time.
13. Press the button twice to return to the Back Comfort
heating configuration screen.
14. Press the button.Heating
15. Press the or button in the screen.Room Supply air Heating
ðYou can either set the room temperature via the Room
button or the supply air temperature(corresponds to the
temperature of the blown-out air) via the Supply air
button.
ðThe room temperature is controlled automatically.
ðThe supply air temperature is maintained at a constant
level.
16. Press the button on the screen to°C specification Heating
either set the room temperature or the supply air
temperature on the next screen.
17. Press the button twice to return to the Back Comfort
heating configuration screen.
18. Press the button.Fan control
19. Press the or button on the Fan controlFixed speed Auto
screen.
ðYou can either set or activate the fixed speed of the fan
via the button or automatic control via theFixed speed
Auto button.
ðIf the button is activated, press the Fixed speed %
specification button to set the fixed speed on the next
screen via the arrow buttons. Then press the Back
button to return to the Comfort heating configuration
screen.
ðWith automatic control, the fan setpoint as a function of
the difference between the current room temperature
and the room temperature setpoint is calculated and
displayed on the screen.
20. Press the button to carry outSupply air limitation
temperature settings of the blown-out air.
21. Press the or button in the Flexible Off Supply air limitation
screen.
ðIf the button is activated, you can alter the fixedFixed
supply air temperature (minimum and maximum
values).
ðIf the button is activated, you can alter theFlexible
flexible supply air temperature (minimum and maximum
limitation values).
Info
If the device is installed in the room to be heated, the
“flexible” setting is recommended. In this way it is
prevent that very warm air will blow on persons
standing or sitting directly near the device.
Alternatively, the supply air temperature can be limited
to a fixed temperature.
ðIf the button is activated, the settings areOff
deactivated. If the supply air temperature
limitation function is switched off, the
maximum limit of the supply air temperature
will be 100°C.
EN 15
vertical heater TAC XT 18 / TAC XT 27
22. Press the button twice to return to the Back Comfort
heating configuration screen.
Pest control
Note
Different pests require different approaches of pest
control. By variation of the temperature and by heating,
thermal pest control can be adapted to the pest
infestation and the room situation.
With the pest control function (PestControl) the pests in the
room where the device is installed are killed off.
1. Press the following buttons in the main menu to carry out
settings regarding the pest control function:
ðConfiguration
ðConfiguration
ðPest control configuration
ðThe following screen will appear, allowing you to carry
out settings regarding the pest control function:
Back
Fan control
Setpoints
Ramp
Configuration PestControl
2. Press the button.Setpoints
ðThe following screen is shown:
Back
60 °C
30 Min
Pest control setpoint
Target temperature
Treatment duration
Configuration
3. Press the button in the Target temperature Pest control
setpoint screen.
4. Press the button to alter the target°C-specification
temperature on the next screen via the arrow buttons.
5. Press the button.Treatment duration
6. Press the button to alter the treatmentMin specification
duration on the next screen via the arrow buttons.
7. Press the button on the Configuration Pest control setpoint
screen to save the settings.
8. Press the button to return to the Back Pest control
configuration screen.
9. Press the button.Fan control
10. Press the button on the screen% specification Fan control
to alter the fan setpoint via the arrow buttons on the next
screen.
11. Press the button to return to the Back Pest control
configuration screen.
12. Press the button to set the ramp for pest control.Ramp
ðThe following screen is shown:
12.3 °C/h123 Min
Time-controlled Increase
Ramp type
Off
Back
13. Press the or button on the Time-controlled Increase Ramp
type screen.
ðIf the button is activated, you can alter Time-controlled
the ramp time. Press the button toMin specification
alter the ramp time on the next screen via the arrow
buttons. After switching on the device, the room
temperature setpoint is increased from the current room
temperature at switch-on to the target temperature
within the ramp time set.
ðIf the button is activated, you can also alter the Increase
ramp time. Press the button to alterMin specification
the ramp time on the next screen via the arrow buttons.
The room temperature setpoint is raised with the
increase specified, starting from the current room
temperature at switch-on until the target temperature
has been reached.
14. Press the button twice to return to the Back Pest control
configuration screen.
HEPA filter operation
If HEPA filter operation is activated, the room air is purified with
the integrated H14 HEPA filter (optional).
1. Press the following buttons in the main menu to carry out
settings for HEPA filter operation:
ðConfiguration
ðConfiguration
ðHEPA filter operation configuration
ðThe following screen will appear, allowing you to carry
out settings regarding HEPA filter operation:
BackSetpoints
Supply air limitation
HeatingTimer operation
HEPA filter operation configuration
Filter regeneration
2. Press the button.Setpoints
ðThe following screen is shown:
Back
20 °C
20 °C
33%
Hepa filter operation setpoint
Room temperature
Outlet temperature
Fan
Configuration
16 EN
vertical heater TAC XT 18 / TAC XT 27
3. Press the button on the Room temperature HEPA filter
operation setpoint screen.
4. Press the button next to the °C-specification room
temperature button to alter the room temperature on the
next screen via the arrow buttons.
5. Press the button next to the °C-specification blow-out
temperature button to alter the blow-out temperature on
the next screen via the arrow buttons.
6. Press the button to alter the air volume°C-specification
flow on the next screen via the arrow buttons.
7. Press the button on the Configuration HEPA filter operation
setpoint screen to save the settings.
8. Press the button to return to the Back HEPA filter operation
configuration screen.
9. Press the button.Timer mode
10. Press the or button on the screen toOff On Timer mode
deactivate or activate the timer.
ðWhen the button is activated, the timer startsOn
running once the device is switched on. When the set
time has elapsed, the device switches off. Press the Min
specification button to alter the operating time on the
next screen via the arrow buttons. Press the Back
button twice to return to the HEPA filter operation
configuration screen.
ðIf the button is activated, the settings areOff
deactivated. Press the button to return to the Back HEPA
filter operation configuration screen.
11. Press the button.Heating
12. Press the or button in the screen.Room Supply air Heating
ðIf the button is activated, you can alter the room Room
temperature. Press the button to set the°C specification
temperature via the arrow buttons. The room
temperature is controlled automatically.
ðIf the button is activated, you can alter theSupply air
supply air temperature (temperature of the blown-out
air). Press the button to set the°C specification
temperature via the arrow buttons. The supply air
temperature is maintained at a constant level.
13. Press the button twice to return to the Back HEPA filter
operation configuration screen.
14. Press the button.Regenerate filter
ðThe following display opens.
Back
Filter regeneration
pre Interval post
Off Off Off
ðThe enabled buttons are shown in black.
15. Press one or several buttons to activate filter regeneration
as follows.
ðpre: filter regeneration is carried out before air cleaning
operation.
ðinterval: filter regeneration is always carried out after a
certain air cleaning operating time. If this function is
activated, the set time will be shown on the screen.
ðpost: filter regeneration is carried out after air cleaning
operation.
Back
Filter regeneration
pre Interval post
Off Off Off
240 Min
Info
Combinations of all three settings are possible, as
shown on the screen below.
16. If is selected, press the displayed time to adjustInterval
the time using the arrow buttons or by entering it directly.
ðDuring the regeneration process, the filter will be heated
to 100°C; the interval is 30minutes.
ðThe (12) is illuminated in blue duringwarning light
filter regeneration.
Warning
Do switch off the device during filter regeneration!not
17. Press the button to alter the minuteMinutes specification
specification setpoint on the next screen.
18. Press the button twice to return to the Back HEPA filter
operation configuration screen.
19. Press the button.Supply air limitation
ðThe supply air temperature limitation is activated once
room temperature control has been selected.
20. Press the or button on the supply air limitationMin Max
screen.
21. Press the button to set the temperature on°C specification
the next screen via the arrow buttons.
22. Press the button twice to return to the Back HEPA filter
operation configuration screen.
23. Press the button.Setpoints
EN 17
vertical heater TAC XT 18 / TAC XT 27
Recommendations for filter regeneration:
Under normal environmental conditions, such as those
prevailing in offices, schools, kindergartens or public buildings,
it is sufficient to regenerate the filter once a week. If the air
cleaner is used in cool areas with high humidity levels, e.g. in
slaughterhouses or in the food industry in general, we
recommend to regenerate the filter daily.
Note
During decontamination, an odour may be produced,
which is harmless.
Note
The software monitors whether filter regeneration is
carried out regularly. After 50hours of air cleaning
operation, a message appears with the option of
starting filter regeneration immediately. If filter
regeneration is not started at this time, the number of
days by which filter regeneration is overdue will be
displayed each time the device is switched on.
Surface decontamination
Surface decontamination allows to thermally decontaminate a
variety of different surfaces within closed rooms. In this
operating mode, the room is heated to the temperature set
before. The temperature level is maintained for a defined time.
1. Press the following buttons in the main menu to carry out
settings regarding the surface decontamination function:
ðConfiguration
ðConfiguration
ðConfiguration surface decontamination
ðThe following screen for setting surface
decontamination will appear.
Back
Fan control
Setpoints
Configuration surface decontamination
2. Press the button.Setpoints
ðThe following screen is shown:
Back
65 °C
60 Min
Target temperature
Treatment duration
Surface decontamination setpoint
Configuration
3. Press the button on the Target temperature Surface
decontamination setpoint screen.
4. Press the button to alter the target°C-specification
temperature on the next screen via the arrow buttons.
5. Press the button.Treatment duration
6. Press the button to alter the treatmentMin specification
duration on the next screen via the arrow buttons.
7. Press the button in the Configuration Surface
decontamination setpoint screen to save the settings.
8. Press the button to return to the Back Surface
decontamination configuration screen.
9. Press the button.Fan control
10. Press the button or button in the Fixed speed Auto Fan
control screen.
ðIf the button is activated, press the Fixed speed %
specification button to alter the fan setpoint in the next
screen via the arrow buttons.
ðIf the button is activated, the fan setpoint isAuto
calculated as a function of the current room
temperature. With an increasing room temperature, the
fan speed of 33% increases in a linear fashion.
11. Press the button twice to return to the Back Surface
decontamination configuration screen.
Room decontamination
With the room decontamination function, objects can be
thermally decontaminated within closed rooms. This operating
mode is very similar to the surface decontamination mode.
However, different values are preset for room decontamination,
which are optimised for the decontamination of batches (e.g.
clothing).
1. Press the following buttons in the main menu to set room
decontamination:
ðConfiguration
ðConfiguration
ðRoom decontamination configuration
ðThe following screen for setting room decontamination
will appear:
Back
Timer operation
Room decontamination configuration
Setpoints
2. Press the button.Setpoints
ðThe following screen is shown:
Back
70 °C
30 Min
Target temperature
Fan
Room decontamination setpoint
Configuration
3. Press the button in the Target temperature Room
decontamination setpoint screen.
4. Press the button to set the target°C specification
temperature in the next screen via the arrow buttons.
18 EN
vertical heater TAC XT 18 / TAC XT 27
5. Press the s button in the Fan Room decontamination
setpoint screen.
6. Press the button to set the air volume flow% specification
in the next screen via the arrow buttons.
7. Press the button in the Configuration Room
decontamination setpoint screen to save the settings.
8. Press the button to return to the Back Room
decontamination configuration screen.
9. Press the button.Timer mode
ðThe screen for setting the timer mode will appear.
10. Press the , the or theOperating duration Treatment duration
Continuous operation button.
ðThe settings for the operating duration, treatment
duration and continuous operation cannot be activated
in parallel.
ðWhen selecting the operating duration or treatment
duration, the supply temperature is maintained at a
constant level.
ðWith the activation of the treatment duration, the time
that has been set starts running as soon as the room
temperature set is reached.
ðWith the activation of the operating duration, the time
starts running as soon as the device is switched on.
ðWith activation of continuous operation, the device must
be switched off manually.
11. Press the button to return to the Back Room
decontamination configuration screen.
Switch-off
Warning of hot surface
Parts of this appliance can become very hot and cause
burns. Particular attention is to be paid when there are
children or vulnerable persons present!
Warning of hot surface
The room temperature may increase up to75°C
during operation.
Note that the surfaces in the room may be hot after the
treatment.
1. Actuate the or button( ) in the main menuOff Start/Stop 18
display on the device. Once the timer has been
programmed, the device switches off automatically.
ðThe fan keeps running for approx. 3minutes to
dissipate the residual heat from the heating elements.
2. Switch the device off afterwards by turning the main
switch to position.0
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
1. Proceed as described in the Switch-off section.
2. Hold onto the mains plug while pulling the it out of the
mains socket.
3. Clean the device according to the Maintenance chapter.
4. Store the device according to the Storage chapter.
Available accessories
Warning
Only use accessories and additional equipment
specified in the instructions.
Using insertion tools or accessories other than those
specified in the instructions may cause a risk of injury.
Warning
In order to prevent a potential fire hazard, only use the
original Trotec .heat-resistant H14HEPAfilter
Designation Article number
DualHeat blowing-out tower 6.100.007.060
Attachment hood for hose
connection
6.100.007.061
Heat-resistant H14HEPAfilter 7.160.000.106
Hygrostat HG 125 6.100.002.042
Prefilter ePM 10 85 % (F7) 6.100.007.062
Prefilter COARSE 75 % (G4) 7.160.000.457
Filter insert for HEPA filter H14 6.100.007.074
Power distributor PV30 32A on
2 x 16A
6.100.002.081
EN 19
vertical heater TAC XT 18 / TAC XT 27
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The device does not start:
• Check the power connection.
• Check the power cable and mains plug for damage.
• Check the mains plug for damages.
• Check the on-site fusing.
• Check whether the device is standing upright and on level
ground. The tilt protection may have been tripped owing to
the fact that the device was knocked over. Always put up
the device in an upright position on a suitable, sufficiently
dimensioned surface.
• The safety thermostat might have tripped due to
overheating Switch the device off and let it cool down for
at least 10minutes.
• The room thermostat might be defective. Have a defective
room thermostat replaced by a specialist electrical
company.
• The overheating protection may have been tripped. Have a
specialist electrical company or Trotec check the electrics
and replace the overheating protection.
The device is loud or vibrates:
• Check whether the device is set up in a stable and upright
position.
The device gets very warm, is loud or is losing
performance:
• Check the air inlets and air filters for dirt. Remove external
dirt.
• From the outside, check the device for dirt (see chapter
Maintenance). If the inside of the device is dirty, have it
cleaned by a specialist company or by Trotec.
The device still does not operate correctly after these
checks:
Please contact the customer service. If necessary, bring the
device to an authorised specialist electrical company or to
Trotec for repair.
Error messages
The following error messages can be indicated on the
display( ):17
Note
At room temperatures above65°C, the display will be
switched off. If the temperature drops below 65°C, the
display is connected again.
Message Cause Troubleshooting
Airflow too low The fan is not
working or the fan
speed is too low.
Possibly the intake
grille, filter or
suction tube is dirty.
Restart the device
and ensure that the
fan is working or
increase the fan
speed.
Check the intake
components for dirt
and clean them if
required.
Filter dirty The air filter is
contaminated.
Replace the filter.
Overheating
protection room
temperature
The adjusted room
air temperature has
been exceeded.
Switch the device
off and allow the
room to cool down.
Overheating
protection motor
The device is
overheating.
Disconnect the
device from the
mains and allow it
to cool down.
Sensor fault A temperature
sensor is defective.
Switch the device
off and check the
temperature
sensors.
Maintenance
Trotec electric heaters are designed for long hours of operation
with minimum maintenance effort. Safe operation of the device
requires all built-in components, especially the safety
temperature limiter(STB), to be checked and cleaned after
6months at the latest or after every 4,000 operating hours as
well as all damaged components to be replaced.
Prior to cleaning the interior, protect the fan and further
electrical components from water ingress with appropriate
means.
20 EN
vertical heater TAC XT 18 / TAC XT 27
Maintenance intervals
Maintenance and care interval before every
start-up
as needed at least every
4weeks
at least every
6months
at least
annually
TAC XT2-3 years
Check air filter, air inlets and outlets
for dirt and foreign objects and clean
ifnecessary
X
Exterior and interior cleaning X
Visually check the inside of the device
for dirt
X
Replace HEPA filter (optional) X
Replace G4Z-line prefilter X
Clean or replace the protective fleece
at the air outlet
X
Clean or replace the prefilter fleece X
Check for damage X
Check the attachment screws X
Test run X
Maintenance and care log
Device type: ............................................. Device number: ....................................
Maintenance and care interval 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Check air filter, air inlets and outlets
for dirt and foreign objects and clean
ifnecessary
Cleaning the exterior
Visually check the inside of the device
for dirt
Replace HEPA filter
Replace the G4Z-line prefilter
Clean or replace the protective fleece
at the air outlet
Clean or replace the prefilter fleece
Check for damage
Check the attachment screws
Test run
Remarks:
1. Date: ........................................
Signature: .....................................
2. Date: ..........................................
Signature: ......................................
3. Date: ..........................................
Signature: ......................................
4. Date: ..........................................
Signature: ......................................
5. Date: ........................................
Signature: .....................................
6. Date: ..........................................
Signature: ......................................
7. Date: ..........................................
Signature: ......................................
8. Date: ..........................................
Signature: ......................................
9. Date: ........................................
Signature: .....................................
10. Date: ........................................
Signature: ......................................
11. Date: ........................................
Signature: ......................................
12. Date: ........................................
Signature: ......................................
13. Date: ......................................
Signature: .....................................
14. Date: ........................................
Signature: ......................................
15. Date: ........................................
Signature: ......................................
16. Date: ........................................
Signature: ......................................
EN 21
vertical heater TAC XT 18 / TAC XT 27
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Warning of electrical voltage
Maintenance tasks and repair work may only be
performed by qualified electricians or Trotec.
Warning
Observe local provisions and regulations on hygiene
when cleaning. Protect yourself during cleaning and
maintenance work with suitable protective equipment
(e.g. protective mask, protective glasses and gloves).
Note
Prior to cleaning the interior, protect the fan and further
electrical components from water ingress with
appropriate means.
Cleaning the housing
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.
Visual inspection of the inside of the device for dirt
1. Remove the air filter.
2. Use a torch to illuminate the openings of the device.
3. Check the inside of the device for dirt.
4. If you see a thick layer of dust, have the inside of the
device cleaned by a specialist company or by Trotec.
5. Put the air filter back in.
Changing the filter
The filter change intervals depend on the degree of air pollution
and the filter quality. Dirty filters impair the performance ability
of the device. When a certain degree of pollution of the filter is
reached, a warning is shown on the display. In this case,
reinsert a new filter.
Info
If a warning to change the HEPA filter is displayed, first
check whether the prefilter fleece is dirty. Replace the
HEPA filter with a new filter if you have replaced or
cleaned the prefilter fleece and the warning message
is still indicated.
Please proceed as follows to change the HEPAfilter:
1. Using a screwdriver, remove the protective caps of
the4screws from the top of the device.
2. Remove all4screws.
1
3. Take off the blowing-out tower( ) from the device and1
carefully put it aside.
22 EN
vertical heater TAC XT 18 / TAC XT 27
4. Remove the HEPA filter( ) and the filter insert( ) from10 11
the device.
10
11
5. Put the worn HEPA filter in a bag and dispose of it in the
waste.
6. Thoroughly clean the housing from the inside and outside
(see Cleaning the housing).
7. Reinsert both the filter insert( ) and the new HEPA filter11
into the device.
10
11
8. Fit the blowing-out tower( ) back on the device.1
1
9. Fasten the blowing-out tower by means of the screws.
10. Put the protective caps back on the screws.
Please proceed as follows to change the prefilter:
1. Loosen the screws on the air inlet( ) on both sides and8
pull out the air inlet towards the front of the device.
2. Remove the prefilter( ).21
821
3. Insert the new prefilter into the device.
ðObserve the installation direction. The black fleece must
be on the outside.
4. Put the air inlet( ) back on the device and tighten the8
screws on both insides of the device.
218
24 EN
vertical heater TAC XT 18 / TAC XT 27
Technical annex Technical data
Parameter Parameter
Model TACXT18 TACXT27
Heating capacity 18kW 27kW
Nominal current 15.9 A / 13.3 A 27.9 A / 13.3 A
Electrical connection CEE 16 A / CEE 16 A CEE 32 A / CEE 16 A
Input voltage 2 x 400 V 3ph / 50-60 Hz 2 x 400 V 3ph / 50-60 Hz
Max. air volume up to 2,500m3/h (without HEPA filter) up to 2,500m3/h (without HEPA filter)
Outlet temperature adjustable up to max. 95°C adjustable up to max. 95°C
Room/ surface target temperature adjustable up to75°C adjustable up to75°C
Automatic control system integrated application programmes for
thermal disinfection, HEPA air
purification, thermal pest control and
room heating
integrated application programmes for
thermal disinfection, HEPA air
purification, thermal pest control and
room heating
Treatment cycle adjustable from 30 to 300min adjustable from 30 to 300min
Thermostat/ sensor connection 7-pin DIN socket 7-pin DIN socket
Prefilter for air filter COARSE 75 % (G4) COARSE 75 % (G4)
Dimensions (lengthx widthx height) 690 x 630 x 1300 mm 690 x 630 x 1300 mm
Minimum distance to all sides during
operation
30 cm 30 cm
Weight 93.1kg 96kg
EN 25
vertical heater TAC XT 18 / TAC XT 27
Circuits
TAC XT 18
26 EN
vertical heater TAC XT 18 / TAC XT 27
EN 27
vertical heater TAC XT 18 / TAC XT 27
28 EN
vertical heater TAC XT 18 / TAC XT 27
EN 29
vertical heater TAC XT 18 / TAC XT 27
30 EN
vertical heater TAC XT 18 / TAC XT 27
EN 31
vertical heater TAC XT 18 / TAC XT 27
32 EN
vertical heater TAC XT 18 / TAC XT 27
EN 33
vertical heater TAC XT 18 / TAC XT 27
34 EN
vertical heater TAC XT 18 / TAC XT 27
EN 35
vertical heater TAC XT 18 / TAC XT 27
36 EN
vertical heater TAC XT 18 / TAC XT 27
TACXT27
