Vaddio™ EasyUSB™ Solutions

PC Group Audio Conferencing Tools

Part Numbers:

999-8530-000: EasyUSB Mixer/Amp (North America)

999-8530-001: EasyUSB Mixer/Amp (International)

Mics and Speakers (Worldwide)

999-8500-000: EasyMic™ MicPOD

999-8510-000: EasyMic Ceiling MicPOD (White)

999-8515-000: EasyMic Ceiling MicPOD (Black)

999-8560-000: EasyTalk™ Ceiling Speakers (1-Pair Bose® DS 16F)

999-8565-000: EasyTalk Sound Bar Speaker

Mixer/Amp

EasyMic MicPOD

(for table top use)

EasyMic Ceiling MicPODs

 Shown in black with 36” cable and in-ceiling

or on-ceiling electronics module.

 The white Ceiling MicPOD with cable is

also shown

EasyUSB Mixer/Amp

EasyTalk Sound Bar

EasyTalk Ceiling Speakers (1-Pair Bose DS16F

with tile support braces and plenum back cans)

Installation and

User Guide

EasyTalk USB Solutions

Vaddio EasyUSB Solutions - Document Number 342-0449 Rev C Page 2 of 48

Inside Front Cover - Basic Blank

EasyTalk USB Solutions

Vaddio EasyUSB Solutions - Document Number 342-0449 Rev C Page 3 of 48

Table of Contents

Overview: ..................................................................................................................................................................................... 5

Unpacking .................................................................................................................................................................................... 6

EasyUSB Mixer/Amp ............................................................................................................................................................... 6

EasyMic MicPOD ..................................................................................................................................................................... 6

EasyMic Ceiling MicPOD ......................................................................................................................................................... 6

EasyTalk Sound Bar ................................................................................................................................................................ 6

EasyTalk Ceiling Speakers ...................................................................................................................................................... 6

Equipment Descriptions and Call-outs ......................................................................................................................................... 6

Diagram: EasyUSB Mixer/Amp ........................................................................................................................................... 7

EasyMic MicPOD ..................................................................................................................................................................... 7

Diagram: EasyMic MicPOD - Front View ............................................................................................................................ 8

Diagram: Bottom View of EasyMic MicPOD ....................................................................................................................... 9

EasyMic Ceiling MicPOD ....................................................................................................................................................... 10

Diagram: Ceiling Interface Module ................................................................................................................................... 10

Diagram: EasyMic Ceiling MicPOD Array Head ............................................................................................................... 11

EasyTalk Sound Bar .............................................................................................................................................................. 11

EasyTalk Ceiling Speakers .................................................................................................................................................... 11

Room Design & Applications ...................................................................................................................................................... 12

Diagram: Example of Reverberation Effects ..................................................................................................................... 12

Diagram: Noise Criteria Table .......................................................................................................................................... 13

Microphone Placement ............................................................................................................................................................... 14

Diagram: Microphone Critical Distance ............................................................................................................................ 14

Diagram: EasyMic MicPOD and Ceiling MicPOD Sound Quality versus Distance (in feet) .............................................. 14

Loudspeaker Placement ............................................................................................................................................................. 15

Typical Table Installation Arrangements .................................................................................................................................... 15

Diagram: Very Small Conference Room (Huddle Room) ................................................................................................. 15

Diagram: Small Conference Table .................................................................................................................................... 16

Diagram: Large Conference Table ................................................................................................................................... 16

Diagram: Large Conference Table with Ceiling Speakers ................................................................................................ 17

Diagram: Large Conference T

able with Ceiling Speakers and Ceiling Mics ..................................................................... 17

Diagram: Very Big Conference Table with Overflow Seating ........................................................................................... 18

Typical Ceiling Installation Arrangements .............................................................................................................................. 18

System Connection Diagrams .................................................................................................................................................... 19

PC-based USB Conferencing Application: ............................................................................................................................. 19

Diagram: PC with USB 2.0 Basic Conferencing Connection Diagram .............................................................................. 19

Diagram: PC USB Conferencing with External Amplifier .................................................................................................. 20

Diagram: PC USB Conferencing using the Built-in Speakers of the LCD Display ............................................................ 21

Diagram: VC Bridge with PC-Based USB Conference ..................................................................................................... 22

Diagram: Recording or Streaming Application .................................................................................................................. 23

Step-by-Step Installation Instructions ......................................................................................................................................... 24

Produktspecifikationer

Varumärke:	Vaddio
Kategori:	mikrofon
Modell:	EasyMic MicPOD
Höjd:	25.4 mm
Diameter:	177.8 mm
Gränssnitt:	RJ-45
Mikrofonfrekvens:	100 - 12000 hz
Automatisk förstärkningskontroll:	Ja
Produktens färg:	Svart
Mikrofonvikt:	214 g
Anslutningsteknologi:	Kabel
Ljuddämpning:	Ja
Mikrofondämpning:	Ja
Mikrofon känslighet (utnivå):	115 dB
Arbetsfrekvens:	20 - 20000 MHz
Ekodämpning:	Ja
Mikrofon, riktning:	Kardioid
Mikrofon Total Harmonic Distortion (THD):	0.02 %
Mikrofonmått (D x H):	177.8 x 25.4 mm
Typ av mikrofonmixer:	Automatisk
