Issue 1
744 1947
V-2976
RED EMERGENCY CALL SWITCH
INTRODUCTION
The V- Red Emergency Call Switch 2976is
designed to be used with Talkback Page Control
Units with the remote calling feature. The
V-2976 provides a vandal resistant momentary
spring return switch for connection to customer
provided signaling equipment.
DIMENSIONS/WEIGHT
4.50" H x 2.75" W x 1.50" D
(11.43cm H x 6.99cm W x 3.81cm D)
0.2 lbs. (0.09 kg)
FEATURES
Designed to t in a standard single-gang
electrical box.
No external power source required.
Stainless steel vandal resistant call button.
18 gauge steel plate finished in high-gloss
red enamel.
“EMERGENCY ONLY” screened in white
lettering below the call button.
CONNECTIONS/SETUP
1. Connect switch leads from paging control
unit to the two screw terminals on the rear of
the V-26, as shown in the connection 97
diagram.
2. Place V-2976 over standard single-gang
electrical box with minimum depth of
2 inches and fasten in place using the two
#6-32 screws provided.
TECHNICAL ASSISTANCE
When trouble is reported, verify that there are no
shorts or grounds on cabling.
Assistance in troubleshooting is available from
the factory. When calling, you should have a
VOM, a telephone test set available and call
from the job site. Call (540) 563-2000 and press
1 for Technical Support or visit our website at
http://www.valcom.com.
Valcom equipment is not eld repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating company
name, address, phone number, contact person
and the nature of the problem. Send the unit to:
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
