Sida 1/33
4ERMOREGOLATORI
$IGITALI
(4
-ANUALED5SO
5SER-ANUAL$IGITAL(EAT2EGULATORS
- 31 -
User Manual Digital Heat Regulators
Contents
Safety warnings Page 32
Technical specifications Page 32
Description of instrument Page 35
Electrical connections Page 35
Glossary Page 36
Operation Page 41
Setting the regulation parameters Page 41
Parameter menu Page 43
Error messages Page 50
Reference standards Page 51
Dimensions and connection diagrams, 33x75 mm Page 52-55
Dimensions and connection diagrams, 72x72 mm Page 56-57
Dimensions and connection diagrams, 4-DIN Page 58-59
English
- 32 -
User Manual Digital Heat Regulators
During the installation and operation of the instrument, the following
safety instructions should be followed:
Series
Series of digital thermoregulator for regulating the temperature that execute 1B type
actions (EN 60730-1).
of digital temperature regulators satisfying the simplest requirements in
the field of heat regulation. They can be used as heating or refrigeration regulators
and as maximum/minimum alarms.
Three dedicated base models for probe input:
- PTC thermal resistances ( os. emp.P T Coeff.) - Ni100, Pt100 HT NiPt
- NTC thermal resistances ( egative emperature N T Coefficient) HT NTC
- TC thermocouples - J, K, L, R, S, T, E, N HT JK
; or each single model, the probe input can be configured from the keyboard.
; wo probe inputs for the HT NTC models, for the measurement of two temperatures
that can be displayed alternatively by the closure or opening of an outer consensus
to be connected to the instrument, or directly from the keyboard for the 72x72 mm
rear panel version (this version has no digital input).
;Relay capacity: 8A / 250VAC
;Available in versions with 1 or 2 relay outputs with exchange contact.
;Heat re
g
ulators with 3 di
g
it, seven se
g
ment and decimal point display.
TECHNICAL SPECIFICATIONS
SAFETY WARNINGS
1) The instrument should be installed by qualified personnel
2) Read the instructions in this manual carefully
3) Carefully follow the instruction diagrams to install the device
4) Before gaining access to the connector terminals, make sure the conductors
to be connected to the instrument or already connected are not powered
5) Make sure the electric panel in which the device is inserted will prevent
access to the terminals after installation
6) Do not supply power to the device if any part of it is damaged
The instrument must be installed and activated in compliance with current
electric systems standards.
7)
The connection cables should be able to resist the maximum operating
temperature in the form of the maximum ambient temperature + 20 °C
8)
The instruments guarantee main insulation between the low voltage parts
(250 V) and the extremely low voltage parts
10)
9)
Any outside switches connected to the control panel should guarantee
a minimum insulation of 250 V AC at operating temperature, or should be
protected by equivalent insulation
IMPORTANT: In order to avoid malfunctions, the differential of intervention
(DF1 or DF2 parameter) should not be set above 30 °C.
English
