Sida 1/2
49
22
44
COMPLEMENTS FOR CIVIL SERIES
TECHNICAL INFORMATION
LUXY
1 Installation in ush-mounting box with a height of 45 mm
2 Light intensity regulator
3 Intervention brightness regulator
4 Terminals on the back of the device for power supply connection
Not extractable step marker lamp with twilight sensor that turns on automatically in low light conditions
to illuminate the path to follow.
The regulators on the front allow you to set the intensity of the light emitted and the level of brightness
(threshold) below which turn on.
Luxy is small and compact to be installed with discretion in the flush-mounting boxes of any room in the
home and is supplied with adapters that allow installation with the plates of the main civil series.
Step marker lamps with twilight sensor
Code Model Description Colour Power supply
VE766200 Luxy Not extractable step marker lamp with twilight sensor Silver tech 115 ÷ 230 V~
NOT EXTRACTABLE STEP MARKER LAMP WITH TWILIGHT SENSOR
• Light intensity regulator to set the quantity of emitted light
(up to 5 lumens)
• Brightness regulator: to set the brightness level
under which turn on the light (3÷10 lux)
• Function always on or always o
• Compact size: only 1 module occupied in the ush-mounting box
• Adapters that allow adaptability with the main civil series
(see “Adaptable plates”) included in the package
CONNECTION DIAGRAMDIMENSIONS (mm)
Front view Side view Diagram
GENERAL CHARACTERISTICS
TECHNICAL INFORMATION
REFERENCE STANDARDS
Compliance with Community Directives: 2014/35/EU (LVD) and 2014/30/EU (EMCD)
is declared with reference to the following standards: EN 60598-1 • EN 60598-2-2 • EN 61000-6-1 • EN 61000-6-3
Power supply V AC 115 ÷ 230 (-15% ÷ +10%)
Frequency 50/60Hz
Mounting ush
Maximum cables section mm21.5
Light source 1 white led
Luminous intensity 0 ÷ 5lumen
Intervention eld 3 ÷ 10lux
Operating temperature 0 ÷ 35°C
Storage temperature -10 ÷ +60°C
Operating humidity 20% ÷ 90% RH
non condensing
Protection degree IP40
Adaptable plates
ABB Mylos series
Ave S44 series
Bticino Axolute series
Bticino Axolute Air series
Bticino Light series
Bticino Living International series
Bticino LivingLight series (LL)
Bticino LivingLight Air series
Bticino Matix series
Gewiss Chorus series
Vimar Arké series
Vimar Eikon series
Vimar Eikon Evo series
Vimar Plana series
For information on the possibility of using dierent plates
contact the technical assistance service
4
1
3 2
LUXY-ENG-072019
