1

3

49

COMPLEMENTS FOR CIVIL SERIES

TECHNICAL INFORMATION

Power USB

CONNECTION DIAGRAMDIMENSIONS (mm)

Front viewSide viewDiagram

1Installation in ush-mounting boxes with a height of 45 mm

2Type A USB connector

3Terminals on the back of the device for power connection

Power USB is a flush-mounting not extractable battery charger for charging smartphones, tablets,

mobile phones and similar products.

Power USB is compact to be installed with discretion in the flush-mounting boxes in any room of the house

and is supplied with adapters that allow it to be installed with the plates of the main civil series.

USB battery charger

USB BATTERY CHARGER

•Type A USB connector with 1.5 A recharge current

•Compact size: only 1 module occupied in the ush-mounting box

•Adapters that allow adaptability with the main civil series

(see “Adaptable Plates”) included in the package

Adaptable plates

ABB Mylos series

Ave S44 series

Bticino Axolute series

Bticino Axolute Air series

Bticino Light series

Bticino Living International series

Bticino LivingLight (LL) series

Bticino LivingLight Air series

Bticino Matix series

Gewiss Chorus series

Vimar Arké series

Vimar Eikon series

Vimar Eikon Evo series

Vimar Plana series

For information on the possibility of using dierent plates

contact the technical assistance service

CodeModelDescriptionColourPower supply

VE780400Power USB GrigioCompact size USB battery charger for 1 module boxesGrey100÷240 V~

VE780500Power USB BiancoCompact size USB battery charger for 1 module boxesWhite100÷240 V~

VE762400Power USBCompact size USB battery charger for 1 module boxesSilver Tech100÷240 V~

REFERENCE STANDARDS

Compliance with the Community Directives: 2014/35/EU (LVD) and 2014/30/EU (EMCD)

is declared in reference to the following harmonized standards: EN 60598-1 • EN 60598-2-2 • EN 61000-6-1 • EN 61000-6-3

Power supply100 ÷ 240V AC

Frequency50/60Hz

Maximum absorptionVA (W)22.5 10

Mountingush

Maximum cables sectionmm

2

1.5

Output

- voltageV DC5 ±0.25

- maximum currentA1.5

- maximum powerW7.5

Operating temperature0 ÷ 40°C

Storage temperature-20 ÷ 40°C

Operating humidity20% ÷ 90% RH

non condensing

Protection degreeIP40

GENERAL CHARACTERISTICS

2

POWER USB-ENG-072019
