Table of Contents Rev. 7/27/2020 MEZZ-200 MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Co. Page 1 of 11
MEZZ-200; MEZZ-200-A; MEZZ-200-SS; MEZZ-200-DW;
MEZZ-200-DW-A; MEZZ-200-DW-SS
Mezzanine Gate Systems
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it
on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at http://www.vestilmfg.com/parts_info.htm.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Page
Signal Words……………………………………………………………….…………………………..……
2
Safety Instructions………….………..………………………………………………………….….......…..
2
Specifications………….…………………………………………………….……………………...…….....
3
Exploded Views and Bills of Materials….......................................................................................
4, 5, 6, 7
Installing the Gate System………….…………....……………………………………………..………….
8
Assembling the Gate System……...……………………………………….………………………………
9-10
Using the Gate System……………….…………………….……………….………………..…………….
10
Record of Satisfactory Condition…………………………………………………………………………..
10
Inspecting and Maintaining the System………………………………………………………….……….
10
Labeling Diagram.…………..………..……………………………………………...................................
10
Limited Warranty……………………………………..……………………………………………………...
11
Table of Contents Rev. 7/27/2020 MEZZ-200 MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Co. Page 2 of 11
SIGNAL WORDS
This manual uses SIGNAL WORDS to draw attention to uses of the product that could result in
personal injuries, as well as the probable seriousness of those injuries. Other signal words call attention to uses
likely to cause property damage. Signal words used in this manual appear below along with the definition of
each word.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product.
SAFETY INSTRUCTIONS
Vestil strives to identify all foreseeable hazards associated with the use of its products. However,
material handling is dangerous and no manual can address every conceivable risk. The most
effective
way to prevent injury is to apply sound judgment whenever using this device.
If this product is assembled, installed, and/or used improperly or carelessly, serious
personal injuries or death might result.
• Read and understand the entire manual before assembling, installing, using or servicing this gate
system. Keep a copy of this manual in an accessible location known to all persons who use the gate
system.
• Keep the bottom gate down at all times except when placing or removing materials inside the gate.
• DO NOT modify the product in any way without first obtaining written approval from Vestil. Unapproved
modifications automatically void the LIMITED WARRANTY (p. 11) and might make the product unsafe to
use.
• Inspect the product as described in the INSPECTING AND MAINTAINING THE SYSTEM section on p.
10. DO NOT use this product if the gate system is damaged. Examples of damage include, but are not
limited to, the following: 1) Cracked, broken or significantly deformed frame members; 2) cracked welds;
3) corrosion, severe wear, or other condition that interferes with normal operating condition. Replace
every part that fails to pass an inspection. DO NOT use the product until it is fully restored to normal
condition. If the gate cannot be restored to normal condition, permanently remove it from service.
• DO NOT use this device UNLESS all labels are readable and undamaged. See LABELING DIAGRAM
on p. 10.
Proper maintenance is essential for this product to remain in normal condition for as long
as possible.
o Keep the product clean & dry.
o Periodically lubricate pivot points.
o Routinely check the soundness of the entire structure. All frame members should be rigid and straight.
Fasteners should be securely connected and undamaged.
