TABLE OF CONTENTS Rev. 6/23/2021 STRAP-WALL MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Corp Page 1 of 7
STRAP-WALL
Instruction Manual
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered, record a
complete description of it on the bill of lading. If the product is undamaged, discard the
packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and
maintenance comply with laws, regulations, codes, and mandatory standards applied where
the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts,
labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
Department can also be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-manuals.php
.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Page
Signal Words….………….…..………..………………………………………………………………….….
2
Safety Instructions…….…….………………………………………………..…………………..……….…
2
Specifications…………….……………………………………………………………………….…………
3
Anchoring the Unit to a Wall………………………………………………………………………………
3
Exploded View & Bill of Materials……………………………….……...…………………………….….
4
Loading Strap Material……………….…………………………………………………………………….
5
Dispensing Strap Material…………………………………………………………………………..………
5
Record of Satisfactory Condition………………………………………………………………….……..
5
Inspections & Maintenance…………………………………………………………………………...….
6
Labeling Diagram……...…………………………………………………………………...…………….…
6
Limited Warranty…...…………………………………………………………………………………….…
7
TABLE OF CONTENTS Rev. 6/23/2021 STRAP-WALL MANUAL
TABLE OF CONTENTS Copyright 2021 Vestil Manufacturing Corp Page 2 of 7
SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood that a particular action will
cause personal injuries or
property damage. Signal words also specify the level of seriousness
of injury if the product is misused in the ways
described. The following signal words are used in
this manual.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
SAFETY INSTRUCTIONS
Vestil strives to identify all hazards associated with the use of our products. However, material
handling is dangerous and no manual can address every risk. The most effective way to avoid
injury is for the end-user to exercise sound judgment whenever using this product.
WARNING
Risks of serious personal injuries or death.
•
Read and understand the entire manual before assembling, installing, using or servicing the
product. Read the manual to refresh your understanding of proper use and maintenance
procedures whenever necessary. Properly maintain the device following to the instructions on
p. 6.
• DO NOT remove, alter, or obscure any label. If a label is missing, damaged, or unreadable,
contact the TECHNICAL SERVICE AND PARTS DEPARTMENT to order a replacement. DO NOT
use the
unit
until all replacement labels are applied. DO NOT remove or obscure any label.
• DO NOT climb, or allow others to climb, on the unit.
•
DO NOT set items on top of the unit or apply loads other than properly sized
spools of strapping material to it. Do not sit on the spool holding mechanism, i.e.
retaining discs. Only use this device to hold and dispense strapping
material.
•
Install the unit in a dry location that is protected from weather.
•
Do not modify this product without express, written consent from Vestil. Unauthorized
modifications automatically void
the LIMITED WARRANTY (see p. 7) and might make the
product unsafe to use.
• DO NOT exceed the capacity/maximum rated load. See Label 1153 on product; also see
LABELING DIAGRAM on p. 6.
• DO inspect the product according to the instructions in INSPECTIONS & MAINTENANCE on p.
6. DO NOT use the product unless it is in SATISFACTORY CONDITION.
• DO NOT modify the product without written approval from Vestil. Unapproved modifications
automatically void the LIMITED WARRANTY (p. 8) and might make the product unsafe to use.
!
