Sida 1/26
I P S u r v e i l l a n c e
Installation Guide
AE Series
Rev. 1.3
Outdoor Housing
Ordering part no.:
AE-238 900041102G
AE-239 900041202G
AE-243 900041902G
AE-244 900042402G
AE-23A 900042302G
AE-23B 900042201G
AE-23C 900041701G
AE-23D 900041801G
AE-23E-v2 900060000G
AE-23F 900042100G
2
I
Model Number AE-238, AE-243 AE 3A, AE 3B, AE--2 -2
23C, AE-23D
AE-239, AE-244 AE-23E-v2, AE-23F
Power Input 24V AC/ DC 24V AC/ 28V DC PoE: 50~57V DC PoE 802.3 bt, (AE-23E-v2)
PoE 50~57V DC, (AE-23F)
Max. Output power
budget
30W 80W, 100W (-AIW) 30W 15.4-30W PoE
30-60W PoE
60W - 95W PoE
Power Consumption Window heater: 10W;
Blower: 2W; Camera: 6 ~
8W
Window heater: 10W;
Blower: 2W; Camera: 6
~ 8W; Cold start heater:
30W
Window heater: 5W;
Blower: 2W; Camera: 6 ~
8W; IR: 6W
Window heater: 10W;
Blower: 2W; Camera: 6 ~
8W; Wiper: 6W
Environmental
Operation Temp.
-20°C ~ +65°C -20°C ~ +65°C
-20°C ~ +50°C (w/ IR)
-40°C (Cold start)
-20°C ~ +65°C
-20°C ~ +50°C (w/ IR)
-20°C ~ +65°C
-20°C ~ +50°C (w/ IR)
Window heater ON/OFF ≤ 30°C ON; ≥ 35°C OFF ≤ 30°C ON; ≥ 35°C OFF ≤ 30°C ON; ≥ 35°C OFF ≤ 30°C ON; ≥ 35°C OFF
Blower Control ≥40°C ON; ≤ 35°C OFF ≥40°C ON; ≤ 35°C OFF ≥40°C ON; ≤ 35°C OFF ≥40°C ON; ≤ 35°C OFF
Protection Level IP67, IK10 IP67, IK10 (IP66 w/ wiper) IP67, IK10 IP67, IK10 (IP66 w/ wiper)
Construction Die-cast Aluminum Alloy Die-cast Aluminum Alloy Die-cast Aluminum Alloy Die-cast Aluminum Alloy
Coating White epoxy powder
coating
White epoxy powder
coating
White epoxy powder
coating
White epoxy powder
coating
Dimensions 415 (L) 170 (W) 125 (H) x x
mm
502.8 (L) x 170 (W) x
135.5 (H) mm
415 (L) x 170 (W) x 125 (H)
mm - IR not included
502.8 (L) x 170 (W) x 135.5
(H) mm - IR not included
Net Weight 2,2kg (4.84 lb) 2, g (5.95 7k lb 8k), 2, g (6.18
lb - wiper model)
2,2kg (4.85 lb) 2,7kg (5.95 lb), 2,8kg (6.18
lb - wiper model)
UNPACKING:
Unpack carefully. Electronic components can be damaged if improperly handled or
dropped. If an item appears damaged in shipment, place it properly in its carton and
notify the shipper.
IMPORTANT!:
1. Read and follow Instructions: All operating and user instructions should be read and
followed before the unit is to be operated.
connections.
If you plan to install this camera enclosure into a tropical, sea coastal, or an environment
where salt water or corrosive industrial waste water/moist are present, please seal each
This will help prevent
electrolysis to occur and extend the life span of the camera and housing.
3
Revision History:
Rev. 1.0: Initial release.
Rev. 1.1: Added the Accessory list and updated environmental parameters: Added the distribution board
drawing for the AE-23E and -23F.
Package Contents:
1. T30 L wrench.
2. 2x M4x8
3. Truss head screw: 1x 1/4"-20X1/4"
4. Truss head screw: 1x 1/4"-20X3/8"
5. 1x Plastic buffer plate:
IMPORTANT:
1. Disconnect devices: A readily accessible disconnect device in the building installation wiring
should be incorporated.
2.
Rev. 1.3 revise specification and part number of AE-23E/23F
