Sida 1/6
QuadruPLE LOw
FREqUENCY OSCILLATOR
mOdEL Of 1974
SALUT
Thankyouforpurchasingthis
XaocDevicesproduct.Batumiisa
fullyvoltagecontrolledquadruple
digitalLFOmodulewithaslewof
interestinganduser-customizable
features.Eachoscillatorcanbe
usedindependentlyorinoneof3
inparagraphs1to4.Thetotalfre
-
quencyrangespansfrom28hours
involtagecontrolled
dividemode,
upto500Hz.Trulycompact(only
10hp),economicallyattractive
yetuncompromised,Batumiis
aperfectsolutionforportable
modularsetups,butcanempower
anysystemsignicantly.
THE mOduLE ExPLainEd
MINI USB
CONNECTOR
[RTFM]
PDATE
wavEfOrm SELEcTiOn
Saw uP
Saw dOwn
TRIANGLE
TRAPEZOID
POwEr
CONNECTOR
–
12
+12
rEv. 09–2014
BATUMI
1974 Quad LOw frEQuEncY OSciLLaTOr
TAP TEMPO MODE
FREE qUAD PHASE DIVIDE
HZ
DIV
•BATUMI•
1974 QuadruPLE LOw frEQuEncY OSciLLaTOr
0.01
0.5
15
0.05
2.5
100
32
8
3
16
4
2
0
180
360
90
270
SINE
SqUARE
SINE
SqUARE
SINE
SqUARE
SINE
SqUARE
FRq FRq PH·DIV FRq PH·DIV FRq PH·DIV· · ·
Saw
ASGN
Saw
ASGN
Saw
ASGN
Saw
ASGN
RESET
SYNC
RESET
SYNC
RESET
SYNC
RESET
SYNC
GETTING STARTED
Ensurethatyouhave10hpfree
spaceinyoureurorackcabinet
andturnthepowero.Now,plug
theprovidedribboncableintothe
toitspinoutandorientation.The
redstripe(andawhitedot)indi
-
catethenegative12Vrail,andis
supposedtopointthesameonthe
busboardaswellastheunit.The
modulehasbeensecuredagainst
reversedpowerconnectionbut
itisalwaysagoodhabittopay
attentiontothis.Now,mountthe
screwsprovidedandswitchyour
systembackon.
mOduLE OvErviEw
EachLFOsectionisidenticaland
consistsofthesameelements.
Thesliderpotentiometer
1
allows
youtomanuallyadjustoneofthe
fourmainparameters,dependent
ontheglobalmodechosen.Forthe
rst—masterLFO—itisalwaysthe
PANEL CONTROLS JUMPERS (seetext) (seetext)
1
2
7
9
8
11
10
3
4
5
6
frequencyrate(from0.01Hzto
100Hz).In
free mode,alltheslid-
ersdenethefrequencyrate.In
quad and phase mode,sliders2–4
denethephaseshift.In
divide
mode,sliders2–4denethemulti-
plicationofthemasterperiod.
Tomanuallysetthefrequency
ratemoreprecisely,usethe
zoom
mode,describedinparagraph6.
The
frq/ph/divsocket
2
allows
thecorrespondingsliderparam
-
etertobevoltagecontrolled(1V/
is10Vandtheextendedfrequency
range53minutesto500Hzmay
beobtained.
side note:Going
above100Hzyoucanexpectthe
waveformstobelesspreciseand
theoutputamplitudelowered.
The
reset/syncsocket
3
isan
user-denedtriggerinputthat
canserveaseithercycleresetor
externaltemposync.Detailstobe
foundinparagraph5.
The
sine socket
4
outputsasine
waveform(–5to+5V).Inquad
andphasemodes,thesinesare
shiftedinrelationtoeachother.
The
saw/asgn socket
5
outputs
eitheradefaultupwardssaw
waveform(–5to+5V)orone
oftheuser-selectableshapes,
describedinparagraph7.
The
square socket
6
outputsa
squarewaveform(–5to+5V).
TheLFOsyncmodetogglesection
6
allowsyoutosetthefouroscil-
latorstorunfreeorsyncedtothe
master,asfollows:
1. frEE LfO mOdE
Toenterthismode,clickthe
centralbuttonuntilthered,
free
LEDlightsup.
Now,anyofthefourLFOsworks
independently.
2. qUADRATURE LFO MODE
Clickthecentralbuttonuntilthe
yellow,
quadLEDlightsup.
TherstLFOisamaster
controllingthefrequencyforall
theremainingLFOs,theneach
subsequentLFOgeneratesawave
thatis90ºshiftedinrelationtothe
precedingone(90º,180º,270º).
Inthismode,slidersandcontrol
inputsforLFOs2–4arenotactive.
3. PHASE LFO MODE
Clickthecentralbuttonuntilthe
yellow,
phaseLEDlightsup.
Similartoquadraturemode,but
allowsthephaseshifttobeset
arbitrarily.
Sliders2–4and
freq inputsare
active.
reset/sync2–4inputsare
notactiveinthismode.
a tip: In phasemode,patchoneof
theLFOstocontrolthephaseshift
ofanother.Stacking2ormore
LFOsresultsinverycomplex,
interestingwaveforms.
4. dividE LfO mOdE
Clickthecentralbuttonuntilthe
blue,
divideLEDlightsup.
LFOs2–4aresyncedtotherst
(master)oneandtheirfrequency
ratesaresubdivided.Sliders2–4
denethemultiplicationratio.
Resultingcycleratescanbe2,3,4,
8,16or32timesslowerthanthe
primary,masterLFO’scycle.
reset/sync2–4inputsarenot
activeinthismode.
5. rESET & SYnc mOdE
Thereset/syncinputcanserve
twodierentpurposes.
In
resetmode,anincomingtrig-
gerimpulseresetstheLFOcycleto
zerostate(hardsync).
In
syncmode(defaultsetting)the
LFOfrequencyratecanbeslaved
toanexternalclocksourceor
tappedviamanualgate.
Thesemodesareselectableby
thejumper
8
ontheback(no
jumperfor
reset,jumperpresent
for
sync).
6. zOOm mOdE
Holdthecentralbuttonfora
seconduntilthecurrentmodeLED
startstoblink.Nowyoucanadjust
thefrequencyratesmuchmore
precisely,aroundthecentralvalue
—astheslidertravelisupscaled.
Holdthebuttonagaintoleavethe
zoommode.
7. aSSignaBLE wavEfOrmS
Thesaw/asgnoutputcanbe
alteredtoprovideotherwaveform
typesaswell.Inthedefaultrm
-
ware,therearefourwaveform
typestochoosefrom:sawup
-
wards,sawdownwards,triangle
andtrapezoid.Toassignthede
-
siredwaveform,usethejumpers
cluster
9
ontheback,according
tothelegendprintednearby.
firmwarE uPdaTES via uSB
Thisdoesnotendhere.Thereare
somealternatermwarerevisions
planned,allowingi.e.dierent
waveformstobeassigned.The
popularMiniUSBstandardport
10
allowsaneasyandstraightfor-
instructionswillbebundledwith
thermwarepackageavail
-
ableonline.caution! Orientthe
updatejumper
11
inthe‘on’state
(jumpingtheleft2pins)onlywhile
updatingthermware!Otherwise
orienttothe‘o’state(theright
twopins).
