APPROVED
BY THE PEOPLE’S COunCiL
fOr MuTuaL ECOnOMiC aiD
VOLTaGE DiSTriBuTOr
SYnTH uTiLiTY MODuLE
MODEL OF 1983
PrODuCT fEaTurES
TECHniCaL DETaiLS
• 2independent1:4bufferedmultiples
• 2voltageinverters
• summing4:1mixersection,
normalledtomultiples
• unitygaincircuit
• backwardpowerprotection
• eurorackstandardsynthesizer
module,fullyDoepfercompatible
• 6hpwide
• +12/-12Vpowered
• currentdraw:5omA
THE MODuLE EXPLainED
ViSiT fOr uPDaTES, ManuaLS, TuTOriaLS anD ParaPHrEnaLiaXAOCDEVICES.COM
SaLuT
Thankyouforpurchasing
thisXAOCDevicesproduct.
Warnaisaquiteself-
explanatoryyetextremely
usefulutilitymodulethat
helpsyoutoworkwithcon-
trolvoltagesinyoursystem.
Youcanuseittodistribute
voltagesourcesprecisely,
toswaptheirpolarity,then
tomixyourCVsandaudio
signalstogether.
inSTaLLaTiOn
Unplugyourmodularsystem
fromthepowersourcerst.
Cleara6hpspaceinyour
eurorackcabinet,andplug
thepowerconnectorintothe
busboardsotheredband
pointsrighttowardsthe
–12Vrail(usuallythelower
one).Althoughthemoduleis
protectedagainstbackwards
powerconnections,itis
alwaysagoodhabittopay
attentiontothis.Tightenthe
suppliedmountingscrews
andyou’rereadytogo.
COnTrOLS & OPEraTiOn
Warnasportsvenormalled
sections:twobufferedmults,
twoinvertersandamixer.
Eachmultipleroutestheinput
1
signaltoseparatedoutputs
2
withoutanyvoltageloss.
Warnaisdesignedforunity
gain–ifyouapplyaspecic
voltagetoanyinput
1
,
5
or
7
,itremainsthesameonthe
respectiveoutputs.
Inverters
3
arehardwiredto
multsandinvertthepolarity
ofthesignalappliedtomults.
Thetwo-colourLEDs
4
in-
dicatethestatusofthesignal
applied–yellowfornegative
partofthevoltageandred
forpositive.
Bothmultsarealsonor-
malledtothemixersection
viainputs
5
.Patchingany-
thingtotheseinputsbreaks
thenormalization.Mixer
LED
8
indicatesthestatusof
mixersumoutput
6
.
Ifmixingseveralhighsignals
causesanoverdrive,please
considerattenuatingthem.
4
8
4
2
2
1
6
1
3
3
5
7
5
BUFFERED MULTIPLE SUMMING MIXER INVERTERINVERTER BUFFERED MULTIPLE
WARRANTY INFORMATION•XaOC DEViCES WarranTS THiS PrODuCT TO BE frEE frOM anY COnSTruCTiOn DEfECTS fOr OnE
YEar frOM THE DaTE Of PurCHaSE. DurinG THaT PEriOD anY MaLfunCTiOninG uniTS WiLL BE rEPairED, SErViCED anD CaLiBraTED WiTH
CuSTOMEr COVErinG uP THE aPPrOPriaTE TranSiT fEES•WarranTY DOES nOT COVEr anY PrOBLEMS rESuLTinG frOM THE inCOrrECT
inSTaLLaTiOn Or VOLTaGE SuPPLiED, aBuSiVE TrEaTMEnT Or anY OTHEr OBViOuS uSEr-infLiCTED fauLT•WE arE STiLL HaPPY TO HELP
afTEr THE WarranTY PEriOD, HOWEVEr WE rESErVE THE riGHT TO CHarGE fOr LaBOr, rEPLaCEMEnT ParTS anD TranSiT•in CaSE
Of anY PrOBLEM PLEaSE COnTaCT uS iMMEDiaTELY: infO@XaOCDEViCES.COM• •THE MiGHTY Muff WiGGLErS, uLf XAOC SALUTES
LunDBLaD, CLarKE rOBinSOn, HEnriK n. BjOrKK, PauL SCHuLZ, CODY GarrETT-TaiT, MODuLarnE.infO & COMraDES WOrLDWiDE•aLL
riGHTS rESErVED © 2012 XaOC DEViCES•ManufaCTurEr rESErVES THE riGHT TO CHanGE SPECifiCaTiOnS aT anY TiME•MaDE in EurOPE
