Sida 1/3
ASMB-818 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x ASMB-818 Startup Manual
• 1 x SATA data cables
• 1 x SATA power cables
• 2 x CPU power cables (8P)
• 1 x CPU carrier - E2A (XCC)
• 1 x CPU carrier - E2B (MCC)
• 1 x PCIe I/O support
• 1 x front panel converter cable
• 1 x I/O port bracket
• 1 x M.2 screw
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Standard M/B Functions
• CPU: LGA4710 6th Gen Intel® Xeon® Scalable proces-
sor
• BIOS: AMI 512 Mbit SPI BIOS
• System Memory: 8 x DDR5 6400 MT/s registered ECC
DIMM, Max. capacity 2TB
ASMB-818 Series LGA 4710 6th Gen Intel® Xeon®
Scalable ATX Server Board with 8 DDR5, 3 PCIe x16,
5 SATA3, 4 USB 3.2 (Gen1), 1 M.2, Dual 10GbE, IPMI
Startup Manual
Note: Due to the inherent limitations of older PC ar-
chitectures, the system may not fully detect 2TB
RAM when 2TB RAM is installed.
• SATA Interface: Asmedia ASM1165: 4 x SATA 3.0 (6
Gb/s) via Slim-SAS HD, 1 x SATA 3.0 (6Gb/s)
• Serial Ports: One at the rear I/O, only supporting RS-232
• Watchdog Timer: 255-level timer intervals
• USB Port: Supports up to 4 x USB 3.2 (Gen1) ports (2
rear ports, 2 ports from the onboard 20-pin header) and 5
x USB 2.0 ports (1 x Type-A, 4 rear ports)
VGA Interface
• Chipset: ASPEED AST2600
• Display Memory: 64 MB
• Resolution: Supports VGA, resolution up to 1920 x 1200
@ 60 Hz refresh
Ethernet Interface
• Interface: 10/100/1000/2500 Mbps & 10 GbE Base-T
• Controller: LAN1/2: Intel I226; LAN3/4: Intel X710
Mechanical and Environmental
• Dimensions (L x W): 244x304mm(9.6″x12″)
• Power Supply Voltage: +3.3 V, +5 V, +12 V, +5 Vsb
• Power Consumption (mainboard only, excluding I/O
device): Max. load: +3.3 V @ 0.59 A, +5 V@ 1.92 A,
+12 V @ 6.65 A,+5 Vsb @ 0.01 A, +12V_8P_1 @ 17.22
A, +12V_8P_2 @ 15.91 A
• Operating Temperature: 0 ~ 60°C (depending on CPU)
• Net Weight: 0.97 kg
Theboardhasanumberofjumpersthatallowyoutocongure
your system to suit your application. The table below lists the
function of each of the jumpers and connectors.
Connectors
Label Function
ATXPWR1
ATX 24-pin main power connector
ATX12V1, ATX12V2 Processor power connector (for CPU0)
BH2 For optional battery kit
BIOS_SKT1 BIOS SPI ROM
COM1 Serial port: RS-232
CPUFAN0 CPU FAN connector
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
Register your products on our website and get 2
months extra warranty for free at:
http://www.register.advantech.com
This manual is for the ASMB-818 Series Rev. A1.
Part No. 2042081800
Printed in China
1st Edition
May 2025
Specications(Cont.)
Jumpers and Connectors
