ASMB-586 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 Startup manual
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 COM cable (for connection to real panel)
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
le.AcrobatReadercanbedownloadedat:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
ASMB-586 LGA 1151 Intel® Xeon® E and 8th/9th Core™
MicroATX Server Board with 4 x DDR4, 4 x PCIe,
6 x USB 3.1, 8 x SATA3, Quad/Dual LANs, IPMI
Startup Manual
Standard Functions
• CPU: Intel LGA1151 Xeon E-21xx/22xx and 8th/9th Gen
Core i3/i5/i7 series processors
• BIOS: AMI 256 Mb SPI BIOS
• Chipset: Intel C246
• System Memory: Dual channel DDR4 ECC/Non-ECC
2666/2400/2133MHzunbueredDIMM,Max.128GB
Note: Due to the inherent limitations of the PC archi-
tecture, the system may not fully detect 128 GB
RAM when 128 GB RAM is installed.
• SATA3 Interface: 8 x SATA3 6Gb/s ports to support Intel
Rapid Storage Technology Enterprise with software RAID
0, 1, 10 & 5. (for Windows only)
• Serial ports: Two serial ports onboard, only supports RS-
232 (one can be in rear IO via COM cable connection)
• Keyboard/Mouse connector: Supports standard PS/2
keyboard and mouse via KMBS1 pin header.
• Watchdog timer: 255 level timer intervals (sec/min)
• USB 3.1: Supports up to six USB 3.1 ports, four Gen2
ports in rear I/O and two Gen1 ports from on-board pin
header
• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)
Display Interface
• Chipset: CPU integrated Intel HD graphics controller
• Display Memory: 1 GB maximum shared memory with
2 GB and above system memory installed (BIOS default
is 256MB)
• Resolution:
- Supports VGA up to 1920 x 1200 resolution @ 60 Hz
refresh rate
- Supports DVI up to 1920 x 1200 resolution@ 60 Hz
refresh rate
- Supports HDMI 2.0 up to 2K/4K resolution @ 60Hz
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel
®
I219LM; LAN2 ~ LAN4: Intel®
I210AT (LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU
only)
Mechanical and Environmental
• Dimensions (L x W): 244 x 244 mm (9.6” x 9.6”)
• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb
• Power consumption: Max. load: +3.3 V @ 3.87 A, +5 V
@ 4.11 A, +12 V @ 0.63 A, +12 V (8P) @ 6.28 A, +5 Vsb
@ 0.09 A
• Operating temperature: 0 ~ 60° C (Depends on CPU
speed and cooler solution)
Specications
Packing List
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for ASMB-586 at:
https://advt.ch/searc8f16d
Register your products on our website and get 2 months
extra warranty for FREE at:
http://www.register.advantech.com
This manual is for the ASMB-586 series Rev. A1..
Part No. 2001058611
Printed in China
2nd Edition
January 2020
