PCE-4B13-00 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• PCE-4B13-00 Startup Manual 1st Ed. p/n: 20014B1300

• 2-year quality warranty card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Standard functions

• PICMG 1.3 slots: PCE-4B13-00 supports PICMG 1.3

half-size server grade SHB (PCE-4XXX series)

• PCIe slots: PCE-4B13-00 supports one PCIe p1-x8 slot,

eleven PCIe p1-x4 slot

• PCI slots: N/A

Mechanical and Environment

• Dimensions: 315 x 243.84

• Power supply voltage:+12 V, +5 V, -12 V, +3.3 V +5 VSB

• Power requirements: Refer to the CPU Board, add-on

card & peripherals

• Operating temperature: 0 ~ 60 °C

• Weight: 0.516 kg (weight of board)

PCE-4B13-00

Backplane: 13 Slot PICMG 1.3 Half-size BP for 14-

slot Rackmount Chassis, 1 x PCIe x8, 11 x PCIe x4

Startup Manual

Connectors

Label Function

SHBA1 ~ SHBB1 PICMG1.3 CPU board slot

PPCIE1PCIe p1-x8 slot

PPCIE2 PCIe p1-x4 slot (From PCH)

P1PCIE1-P1PCIE10PCIe p1-x4 slot (From PLX8748)

EATXPWR1ATX2.0 24-pin power connector

VOLT1Alarm board power connector

EATX12V1,

EATX12V2

ATX 12V Auxiliary 8-pin power

connector

FAN1~FAN7FAN connector

FANDEC1FAN detector connector

SMBUS1, SMBUS2

SMBus connector for chasis

monitor

JFP1

Power and Reset button con-

nector

Jumpers

Label Function

PSON1 ATX/AT Mode Selection

JGENSEL1 PCIe generation selection

connector

JCOMP1 Enable compatibility for

non-compliant Gen1 end point

Jumpers and

Connectors

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com.tw/support

This manual is for the PCE-4B13-00 series.

Part No. 20014B1300

Printed in China

1st Edition

November 2014
