Sida 1/11
Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather -091-C Three Channel Display WS
Wireless Thermometer (Console Only) User Manual
Table of Contents
1 Introduction ..................................................................................................................................... 2
2 Getting Started ................................................................................................................................ 2
Parts List ............................................................................................................................................. 3
2.2 Display Console Set Up ................................................................................................................ 3
2.2.1 Display Console Layout ..................................................................................................... 4
3 Console Operation........................................................................................................................... 4
3.1 Channel Selection ......................................................................................................................... 5
3.2 Min and Max Alarm ...................................................................................................................... 5
3.2.1 Turning On and O the Alarm ........................................................................................... 5
3.2.2 Setting the Min and Max Alarm ......................................................................................... 5
3.2.3 Viewing the Min and Max Alarms ..................................................................................... 5
3.3 Reset Max/Min .............................................................................................................................. 5
3.4 Temperature Units of Measure ............................................................................................... 5
3.5 Sensor Search Mode ...................................................................................................................... 6
3.6 Best Practices for Wireless Communication ................................................................................. 6
3.7 Adjustment or Calibration ............................................................................................................. 6
4 Glossary of Terms ........................................................................................................................... 7
5 Specications .................................................................................................................................. 7
5.1 Wireless Specications ................................................................................................................. 7
5.2 Measurement Specications ......................................................................................................... 8
5.3 Power Consumption ...................................................................................................................... 8
6 Troubleshooting Guide .................................................................................................................... 8
7 Accessories ..................................................................................................................................... 9
8 Liability Disclaimer ........................................................................................................................ 9
9 FCC Statement ................................................................................................................................ 9
10 Warranty Information ............................................................................................................... 10
Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 2
1 Introduction
Thank you for your purchase of the Ambient Weather WS-091-C Three Channel Display Wireless
Thermometer (Console Only). The following user guide provides step by step instructions for
installation, operation and troubleshooting. To download the latest manual and additional
troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/ws091c
The WS-091C also includes an indoor channel (there is a sensor inside the display) as well as supports
up to 8 remote sensors (channels 1-3 are always displayed and 4-8 can be displayed in the indoor
section of the display).
The WS-091C supports any combination of the following sensors (sensors are sold separately):
Item Number
Description
F007T
8- nnel sensor measures temperature. Applications cha
include indoor and outdoor temperature measurement.
F007TP
8-channel sensor measures probe temperature.
Applications include refrigerators and freezers (where
the probe is placed inside the appliance(s) and the
display is outside, water temperature, soil temperature
and
F007PF
8-channel pool oat thermometer. Applications include
pools, spas, and lakes.
2 Getting Started
Note: The power up sequence must be performed in the order shown in this section (insert
batteries in the remote transmitter rst, Display Console second). (s)
Version 1.0 ©Copyright 2013, Ambient LLC. All Rights Reserved. Page 3
Parts List
QTY
Item
1
Display Console
Frame Dimensions (LxHxW) 4.50 x 5.0 x 1.00 : in
LCD Dimensions (LxW): 3.75 x 3.50 ”
LCD Segment Height: 1.25 inches
2.2 Display Console Set Up
1. Move the remote thermometer 5 to (s) about 10’ away from the display console (if the sensor
is too close, it may not be received by the display console). If you have more than one probe
thermometer, make sure they are all powered up and transmitting on different channels.
2. Remove the battery door on the back of the display, as shown in Figure 1. Insert four A AA
(alkaline or lithium, avoid rechargeable) batteries in the back of the display console.
Figure 1
All of the LCD segments will light up for a few seconds to verify all segments are operating properly.
3. Replace the battery door, and fold out the desk stand and place the console in the upright
position.
The console will instantly display indoor temperature as designated by the icon. The
remote temperature probes will update on the display within a few minutes on the
appropriate channel.
While in the search mode, the remote search icon will be constantly displayed for each
sensor.
If you have more than two remote sensors (additional channels 3-8 are supported), the
display will automatically toggle between sensors until all sensors have reported in.
Do not touch any buttons until all of the remote sensors has reported in, or the radio search
icon is no longer visible, otherwise the remote sensor search mode will be terminated.
When the remote sensor temperature has been received, the console will automatically
switch to the normal mode, and all further settings can be performed.
