Sida 1/8
Version 1.3 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather - Wireless Indoor / Outdoor WS 40
Thermometer
Table of Contents
1. Introduction ..................................................................................................................................... 1
2. tting Started ................................................................................................................................ 1 Ge
2.1 Parts List ....................................................................................................................................... 1
2.2 Thermometer Sensor Set Up ......................................................................................................... 1
2.3 Display Console Set Up ................................................................................................................ 3
2.4 Sensor Operation Verication ................................................................................................ 4
3. Remote Sensor Installation ............................................................................................................. 4
4. Glossary of Terms ........................................................................................................................... 5
5. Specications .................................................................................................................................. 5
5.1 Wireless Specications ................................................................................................................. 5
5.2 Measurement Specications ......................................................................................................... 5
5.3 Power Consumption ...................................................................................................................... 5
6. Troubleshooting Guide .................................................................................................................... 6
7. Liability Disclaimer ........................................................................................................................ 6
8. FCC Statement ................................................................................................................................ 7
9. Warranty Information ...................................................................................................................... 7
1. Introduction
Thank you for your purchase of the Ambient Weather -40 wireless indoor / outdoor thermometer. WS
The following user guide provides step by step instructions for installation, operation and
troubleshooting. To download the latest manual and additional troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/ws40
2. Getting Started
The -40 wireless indoor / outdoor thermometer consists of a display console (receiver), and a WS
wireless thermometer (remote transmitter).
2.1 Parts List
QTY
Item
1
Display Console
Frame Dimensions (LxWxH) 3.5 x 2.5 x 0.75 : in
LCD Dimensions (LxW) 1.5 x 1.25: ”
1
Thermometer/Transmitter (F007T)
Dimensions (LxHxW): 4.5” x 2.0” x 0.75”
2.2 Thermometer Sensor Set Up
Note: Do not use rechargeable batteries. We recommend fresh alkaline batteries for temperature
Version 1.3 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 2
ranges between -4 and 140 and fresh lithium batteries for temperature ranges between -40 °F °F °F
and 140 °F.
1. Remove the battery door on the back of the sensor by removing the set screw, as shown in
Figure 1 .
Figure 1
2. inserting the batteries, locate the dip switches on the inside cover of the lid of the BEFORE
transmitter. Make sure all of the dip switches are in the down position (the WS-40 only
supports one wireless transmitter).
Figure 2
3. Temperature Units of Measure: To change the transmitter display units of measure ( °F
vs. °C), change Dip Switch 4, as referenced in Table 1.
DIP SWITCH
FUNCTION
1
2
3
4
DOWN
DOWN
DOWN
---
Channel 1 (WS40)
---
---
---
DOWN
°F
---
---
---
UP
°C
Table 1
4. Insert two AAA batteries.
5. After inserting the batteries, the remote sensor LED indicator will light for 4 seconds, and
then ash once per 60 seconds thereafter. Each time it ashes, the sensor is transmitting data.
6. Verify the correct channel number (CH 1) and temperature units of measure (°F vs. °C) are on
the display, as shown in Figure 3.
Version 1.3 ©Copyright 2015, Ambient LLC. All Rights Reserved. Page 3
Figure 3
(1) temperature
(2) temperature units ( °F vs. °C)
(3) channel number
7. Close the battery door. Make sure the gasket (around the battery compartment) is properly
seated in its trace prior to closing the door. Tighten the set screw.
2.3 Display Console Set Up
Note: To avoid permanent damage, please take note of the battery polarity before inserting the
batteries.
Move the remote thermometer at least 5’ away from the display console (if the sensor is too close, it
may not be received by the display console). Remove the battery door on the back of the display.
Insert two AAA (alkaline or lithium) batteries in the back of the display console, as shown i Figure 4. n
All of the LCD segments will light up for a few seconds to verify all segments are operating properly.
Replace the battery door, and fold out the desk stand and place the console in the upright position.
The console will instantly display indoor temperature. The outdoor temperature will display dashes
or .-, then update on the display within a few minutes. --
If the remote sensor does not update, please reference the troubleshooting guide in Section 6.
