- 1 -

M965777 (8/17)

Product names listed herein are trademarks of AS America, Inc.

© AS America, Inc. 2017

RECOMMENDED TOOLS AND MATERIALS

Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing

supply stores. It is essential that the tools and materials be on hand before work is begun.

CARE AND CLEANING

Do: Simply rinse the product clean with clear water, dry with a soft cotton flannel cloth.

Do Not: Clean the product with soaps, acid, polish, abrasives, harsh cleaners, or a cloth with a coarse surface.

SPECTRA DUO

™

Shower HeadFor all Models

Plumbers' Grease

Tubing Cutter

Adjustable WrenchTeon Tape

Channel Locks

Thank you for selecting American Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly-please read

these instructions carefully before you begin.

INSTALLATION

INSTRUCTIONS

1698.254

1695.254

Certied to comply with ANSI A112.18.1M

1

3

1

2

4

5

INSTALL DUAL SHOWER HEAD,

SHOWER ARM WITH FLANGE

• Operate handle back to front, in COLD and HOT

positions, to flush water lines thoroughly.

• Apply sealant or Teon tape to threads on SHOWER

ARM (1).

• Thread SHOWER HEAD (3) onto the SHOWER ARM (1).

• Thread SHOWER HOSE (2) onto SHOWER HEAD (3).

• Place HAND HELD SHOWER (4) in SHOWER HEAD

DOCK (5) to secure it in place.

CAUTION: Protect finish on SHOWER HEAD and

ARM when installing.

CAUTION

Protect finish on SHOWER HEAD

and TUB SPOUT when installing.
