American Standard Spectra 9135073.013 Bruksanvisning
Sidor 3 Duschsystem
Läs bruksanvisningen för American Standard Spectra 9135073.013 gratis online eller ladda ner PDF:en. 7 personer har tyckt att guiden var hjälpsam. Fråga om modellen? Ställ en fråga
- 1 -
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2016
Thank you for selecting American Standard...
the benchmark of fine quality for over 100 years.
To ensure that your installation proceeds smoothly-please read
these instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
M965758 (6/16)
For all Models
Adjustable Personal
Hand Shower Bar
ROUGHING-IN DIMENSIONS:
• For reference
24"
(610 mm)
2-3/8" DIA
(60 mm)
1-7/8"
(48 mm)
5-1/2"
(140 mm)
FINISHED
WALL
WALL SUPPLY
WITH BUILT IN
BACK FLOW
PREVENTER
1/2"
(13 mm)
1-1/16"
(26 mm)
1-7/16"
(37 mm)
1/2 N.P.T.
(13 mm)
(48" - 60") (OPTIONAL)
TO FINISHED FLOOR
(1219 - 1524 mm)
RUBBER GASKET
FINISHED WALL
1/2" NPSM HOSE
CONNECTION (13 mm)
59"
(1499 mm)
6-3/8"
(162 mm)
4-7/8"
(124 mm)
2"
(51 mm)
8-3/16"
(208 mm)
DrillFlat Blade ScrewdriverLevel
10'
Tape Measure
CARE AND CLEANING
Do: Simply rinse the product clean with clear water, dry with a soft cotton flannel cloth.
Do Not: Clean the product with soaps, acid, polish, abrasives, harsh cleaners, or a cloth with a coarse surface.
INSTALLATION
INSTRUCTIONS
Certied to comply with ANSI A112.18.1M
Produktspecifikationer
| Varumärke: | American Standard |
| Kategori: | Duschsystem |
| Modell: | Spectra 9135073.013 |
Behöver du hjälp?
Om du behöver hjälp med American Standard Spectra 9135073.013 ställ en fråga nedan och andra användare kommer att svara dig
