DVI MATRIX USERS MANUAL
AT-DVI0808/AT-DVI0808-A
AT-DVI1616/AT-DVI1616-A
AT-DVI3232/AT-DVI3232-A
AT-DVI3216/AT-DVI3216-A
Safety Operation Guide:
Atlona Technologies www.atlona.com 2
Atlona Technologies www.atlona.com
1.0 Safety Operation Guide
**************************************************************************
In order to ensure the credibility and the user’s safety, please comply with the following
items during installation, maintenance and operation of the switch.
1) The switch must be in stable position. Use only the power supply that
comes with unit. Do not use an alternate as it may damage it.
2) Do not place the switcher near hot or cold surfaces or sources.
3) To avoid any damage by over heating, please keep the environment in good
ventilation to radiate the heat when running the switcher.
4) The switcher should be turned off when it is not used.
5) Please do not attempt to take cover off the switcher for there is a high-volt
age component inside that could cause electric shock.
6) Do not splash any liquid or chemical on or near the equipment.
7) Please make sure all the wiring are in working condition and are not cut or
damaged.
**************************************************************************
This Switchers User Manual can be used for other matrix switcher models. DVI DVI
This manual is only an instruction for operators, not for any maintenance usage.
Any changes of functions and parameters since then will be informed separately. This
manual is copyright Atlona Technologies. All rights reserved. No part of this publication
may be copied or reproduced without the prior written consent of Atlona Technologies.
Please check Atlona website updates.
http://www.Atlona.com
Contents:
Atlona Technologies www.atlona.com 3
Safety Operation Guide............................................................................2
1. Introduction..........................................................................................4
1.1 About the DVI Matrix Switch............................................................4
1.2 DVI Matrix Switch Model..................................................................4
2. Package Contents..................................................................................5
3. Installation............................................................................................5
4. Front and Rear View on the Product.....................................................6
5. Operation and Control..........................................................................6
5.1 RS232, LAN and 3rd Party Control ..................................................6
5.2 Connecting using Input and Output Terminals...................................7
5.3 Connecting and Setting up Audio.......................................................7
5.4 Front Control/ Operation.....................................................................9
5.5 Remote Control Operarion................................................................12
5.6 Operarion Of Application Software..................................................12
5.7 Keyboard Tab...................................................................................14
5.8 Auto Tab...........................................................................................14
5.9 Cusome Code Tab............................................................................15
5.10 Code Group Tab.............................................................................16
5.11 Send/Receive Code List Tab...........................................................17
6. Operation of RS232............................................................................17
7. Technical Specifications......................................................................19
8. Troubleshooting..................................................................................21
