User’s Manual
MODELS: AT-HD14SS
[Rev.0911]
TABLE OF CONTENTS
1. Introduction ....................................................
1
2. Features ....................................................
1
3. Specification
....................................................
2
4. Package Contents ....................................................
3
5. Connection Diagram ....................................................
3
6. Panel Description ....................................................
4
7. Hardware Installation ....................................................
4
8. DIP Switch ....................................................
5
9. Pin Definition ....................................................
6
10. Notice ....................................................
7
11. Performance Guide ....................................................
7
12. Safety Information ....................................................
8
13. Warranty ....................................................
9
14. Product Registration ....................................................
10
INTRODUCTION
1
Atlona Technologies’ AT-HD14SS 1x4 HDMI 1.3 over Single CAT5/6 Distribution Amplifier
provides the most flexible solution in the Audio Video industry at which high definition video and
high quality audio can be transmitted to different locations over a long distance. The splitter is
cascadable, allowing you to daisy chain multiple units for extending HDMI displays almost
anywhere at almost any distance. The input HDMI source can be duplicated and distributed to
up to 4 HDMI enabled displays through cost effective Cat-5/6 cables and RJ-45 to HDMI mini-
extenders (AT-HD15SRS) or long range receivers (AT-HDRS). The built-in re-clocking
technology allows users to connect long distance cables up to 66ft to the input of the Atlona
1x4 splitter.
FEATURES
State-of-the-art Silicon Image (founder of HDMI) chipset used for 99.99% compatibility
and reliability
HDMI 1.3c compliant
HDCP compliant
Regenerates HDMI signal
Supports default HDMI EDID and has the ability to learn the EDID of displays
Extends up to 20m (66ft) of input HDMI cable
Extends up to 60m (200ft) of output Cat-5/5e/6 cable under HD (720p / 1080i)
Extends up to 40m (130ft) of output Cat-5/5e/6 cable under Full HD (1080p)
Uncompressed 7.1ch digital HDMI over Cat-x cable transmission
Cascadable for longer extension
Perfectly integrated with other HDMI over CAT5/6 series products including LYNX CAT
Series
Wall mountable
Note: The length depends on the characteristics and quality of the cables. Higher resolutions and
longer trans- mission distances require low skew cables (<25ns/100m) for best performance.
Unshielded CAT6 with metal
RJ-45 connectors is recommended.
