INSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONS

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/12/25 INSTAXCSD-6V

AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/12/25 INSTAXCSD-6V

Product Info

Product Info

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip ties

12-volt to 6-volt

Step-Down Converter

• Converts 12-volts DC to 6-volts DC to provide proper voltage for a 6-volt factory backup camera

• AXCSD-6V converter with wiring harness

AXCSD-6V

Connections

Black - Chassis ground

Blue/White - Reverse trigger*

Blue/Red - Camera power

*

Accessory power can also be used if the radio

has the option to monitor the camera while in

motion

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip ties

12-volt to 6-volt

Step-Down Converter

• Converts 12-volts DC to 6-volts DC to provide proper voltage for a 6-volt factory backup camera

• AXCSD-6V converter with wiring harness

AXCSD-6V

Connections

Black - Chassis ground

Blue/White - Reverse trigger*

Blue/Red - Camera power

*

Accessory power can also be used if the radio

has the option to monitor the camera while in

motion
