Sida 1/8
Installation instructions for part AXGM-08
REV. 1/20/2020 INSTAXGM-08
axxessinterfaces.com
•
metraonline.com
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Axxess Integrate
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
•
Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake,
reverse, speed sense)
• Retains chimes
• Pre-wired AXSWC harness (AXSWC sold
separately)
• Retains OnStar / OE Bluetooth
• Adjustable OnStar level
• Designed for amplified models
• Retains balance and fade
• AXUSB-CBL (sold separately) updatable
INTERFACE FEATURES
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
• Small flat-blade screwdriver
TOOLS REQUIRED
AXGM-08
GM Data Interface
2005-2006
APPLICATIONS
• AXGM-08 interface • AXGM-08 harness
• 16-pin harness with stripped leads
INTERFACE COMPONENTS
Connections to be made .........................................2
Installing the AXGM-08 ..........................................3
Initializing the AXGM-08 ........................................3
Adjusting the AXGM-08 ..........................................3
Table of Contents
CHEVROLET
Equinox 2005-2006
PONTIAC
Torrent 2006
AXGM-08
2
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the Red wire to the accessory wire.
Note: If installing an AXSWC (sold separately), there will be an accessory wire
there to connect as well.
• Connect the Blue/White wire to the amp turn on wire. This wire must be
connected to hear sound from the factory amplifier.
• If the aftermarket radio has an illumination wire, connect the Orange/White
wire to it.
• If the aftermarket radio has a mute wire, connect the Brown wire to it. If the
mute wire is not connected, the radio will turn off when OnStar is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative output.
The following (3) wires are only for multimedia/navigation radios that require these wires
.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
From the AXGM-08 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• The Black/Yellow wire is used for OnStar level adjustment for models that
do not come equipped with steering wheel controls. Refer to the OnStar level
Adjustment section for further instructions.
12-pin pre-wired AXSWC harness:
• This harness is to be used along with the optional AXSWC (not included) to
retain steering wheel audio controls. If the AXSWC is not being used, disregard
this harness. If it will be used, please refer to the AXSWC instructions for radio
connections and programming.
Note: Disregard the harness that comes with the AXSWC.
• Connect the Red wire to the accessory wire.
Connections to be made
