METRA. The World’s best kits.™metraonline.com1-800-221-0932

© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION

Installation Instructions for AXVI-2104

REV. 1/21/2020 INSTAXVI-2104

(continued on next page)

GM 2006-2012

AXVI-2104

GM LAN 11 accessory and NAV output interface

WIRING THE AXVI-2104

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• The Orange/White wire will not be used in this application. Tape up or cap off this

wire and disregard it.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

• Connect the Gray/Black wire to the right front negative speaker output of the

aftermarket radio.

• Connect the Green wire to the radio’s left rear positive speaker output.

• Connect the Green/Black wire to the radio’s left rear negative speaker output.

• Connect the Purple wire to the radio’s right rear positive speaker output.

• Connect the Purple/Black wire to the radio’s right rear negative speaker output.

CHEVROLET

Cobalt 2007-2010

HHR 2006-2011

Malibu 2008-2012

PONTIAC

G5 2007-2009

G6 (5th digit of VIN must be a J, K, or L) 2009

G6 2010

Solstice 2006-2009

SATURN

Aura 2007-2009

Sky 2006-2009

APPLICATIONS

KIT FEATURES

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

Note:All chimes will be lost when using this harness
