Installation Instructions for AXVI-2105

REV. 8/6/2020 INSTAXVI-2105

(continued on next page)

GM/Suzuki 2006-up

AXVI-2105

GM LAN 29 accessory and NAV output interface

WIRING THE AXVI-2105

• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.

• Connect the Black wire to the radio’s ground wire.

• Connect the Red wire to the ignition wire of the aftermarket radio.

• Connect the Orange wire to the illumination wire of the aftermarket radio. If the

aftermarket radio has no illumination wire, tape off the Orange wire.

• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.

• Connect the White wire to the left front positive speaker output of the aftermarket radio.

• Connect the White/Black wire to the left front negative speaker output of the

aftermarket radio.

• Connect the Gray wire to the right front positive speaker output of the

aftermarket radio.

KIT FEATURES

• Provides accessory (12 volt 10 amp)

• Retains R.A.P. (retained accessory power)

• Used in non-amplified systems or when replacing amplified system

• Provides NAV outputs (parking brake, reverse, and V.S.S.)

• Prewired AXSWC harness included (AXSWC sold separately)

• High level speaker input

• USB updatable

Note:All chimes will be lost when using this harness

BUICK

Enclave 2008-up

Lucerne 2006-2011

CADILLAC

DTS 2006-2011

(only to be used when replacing

an amplified system)

Escalade 2007-2014

(only to be used when replacing

an amplified system)

SRX 2007-2009

(only to be used when replacing

an amplified system)

CHEVROLET

Avalanche 2007-up*

Captiva Sport 2012-up

Cheyenne 2012-up *

Equinox 2007-2009

Express 2008-up

Impala 2006-2013

Impala limited 2014

Monte Carlo 2006-2007

Silverado (new body) 2007-13*

Silverado 2500/3500 2014 *

Suburban 2007-2014*

Tahoe 2007-2014*

Traverse 2009-up

GMC

Acadia 2007-up

Savanna 2008-up

Sierra(new body) 2007-13*

Sierra 2500/3500 2014*

Yukon/XL 2007-2014*

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

Vue 2008-2010

SUZUKI

XL-7 2007-2009

APPLICATIONS

*Non-navigation models only
