Cactus V6 II Bruksanvisning

Cactus Fjärrutlösare V6 II

Läs gratis den bruksanvisning för Cactus V6 II (1 sidor) i kategorin Fjärrutlösare. Guiden har ansetts hjälpsam av 26 personer och har ett genomsnittsbetyg på 5.0 stjärnor baserat på 13.5 recensioner. Har du en fråga om Cactus V6 II eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/1

Major Speciﬁcations

• Workingradiofrequency:2.4GHz

• Numberofchannels:16

• Numberofgroups:4

• Supportssyncspeedupto1/8,000second

• AFAssistLED:1W

• Maximumeffectivedistance:100meters

• Operatingtemperature:-20°Cto+50°C

• Cameravoltagehandling:upto6V

• Flashvoltagehandling:upto300V

• Dimensions:79mm(L)x77mm(W)x48mm(H)

• Weight:96g

• Powerinput:2xAAbattery,3V,50mA,0.15W;mini

US B 2.0, DCi n p ut 5 V

Package Contents

Installing the Batteries

Openthebatterydoor

bypushingitbackward.

Flipopenthelatchand

i n s er t tw o A A b att er ie s 

usingthecorrect

polarities.Thenclose

thebatterydoorby

pushingittothefront.

Attaching to the Camera

UNLOCK

Turnthelockleverto

theRIGHTtoLOCKthe

m u lti- sy st e m sho e t o 

thecamera.

LOCK

Turnthelockleverto

theLEFTtoUNLOCKthe

m u lti- sy st e m sho e f r o m 

thecamera.

Nomenclature

M ULTI-SYST EM 

SHOE(MALE)

HOTSHOE

L O CK L E V E R

BATTERYDOOR

TRIPODMOUNT

LEDSTATUSINDICATOR

M E N UB U T T O N

OKBUTTON

SELECTIONDIAL

L C D D IS P L AY

M ULTI-SYST EM 

SHOE(FEMALE)

X-SYNCPORT

MINIUSBPORT

MODESWITCH

AFASSIST

LIGHT

LANYARD

LOOP

T E ST B U T T O N/ 

SHUTTERRELEASE

BUTTON

G R O U PB U T T O N S

LCD Panel

CHANNEL P O W E R L E V E L P O W E R L E V E L I N C R E M E N T

BATTERYINDICATOR

GROUP

MAIN SCREEN

STATUS SCREEN ( + )

CAMERA 

SYSTEM

P O W E R L E V E L/ 

ZOOM

FLASHPROFILE

FLASH

SYSTEM

SYNCMODE

INDICATOR

R E L A Y M OD E 

INDICATOR

DELAY

TIMER

TX Mode

RX Mode

WIRELESS

SENSITIVITY

CHANNEL

BATTERYINDICATOR

FLASH

PROFILE

P O W E R L E V E L 

INCREMENT

POWER

LEVEL

DELAY

TIMER

R E L A Y M OD E 

INDICATOR

FLASH

SYSTEM

Cautions and Warnings

BeforeusingyourV6II,readthefollowingsafety

pr e c a utio n s t oe n s u r e c or r e ct a n d s afeu s e:

• TurnOFFallyourequipment(e.g.,Cactusunits,

 a s h u n its, ca mer a s, et c.)b ef or e ch a n g i n g 

batteries.Observethecorrectpolaritywhen

changingbatteries.Thereisadangerof

explosionifthebatteriesareinstalled

i n co r r e ctl y.

• Switchoffthetransceiverandremovebatteries

d u r i n g st or a g e.

• Donotdisassemble.

• DonotcrushtheV6IIanddonotitexposeto

a n y s hoc ko rf or ces uch a s h a m m eri n g, d r o p pi n g, 

orsteppingonit.

Choose the Operation Mode

SettheV6IItransceiverto

thecorrectmode(transmitter

t o“ T X”,r eceiv er t o“ R X”) by 

slidingthemodeswitchtothe

cor r e ct p ositio n.

Setting & Selecting the Group

• TX:Activateany

co m bi n atio n of g r o ups 

bypressingthegroup

buttons.

• RX:Seteachunitto

Gr o upA, B, C, or D by 

pressingthegroup

button.EachRXcan

onlybeassignedtoONE

group.

Setting the Channel

SetallofyourV6IItransceiverstothesame

ch a n n el (e.g.,c h a n n el 10):

<RADIOSETUP>

Camera and Flash Indicators

Canon Fujifilm Nikon

Olympus

(M43)

Pentax Others

     

   

Camera and Flash Compatibility

Camera System Compatible Flash System



 

 

V6 II T r a n s c eiv er

Fl a s h S t a n d F S-2

Q u ic k St a r tG ui d e 

&Album



FujifilmashesdonotsupportHSScapabilities.

RF60/RF60X

Wireless

Flash

Transceiver

V6 II

Q u ick St a r tG u id e

Produktspecifikationer

Varumärke:	Cactus
Kategori:	Fjärrutlösare
Modell:	V6 II
Produkttyp:	Transmitter
Inbyggd display:	Ja
Kompatibilitet:	320EX, 420EX, 430EX, 430EX II, 430EX III, 580EX, 580EX II, 580EX III, 600EX-RT
Produktens färg:	Svart
Kameramärken-kompatibilitet:	Canon
