Owner’s Manual
Part number 47830-59-00
Dec 2020
GXLD2QM
1. ON/OFF Switch
2. Antea nn
3.Charge indicator, Red charging, Green charged
4. DC 5V charging port
1.ON/OFF switch
2.Freency Selection Button qu
3.Freency Disay qupl
4.Baery Compartment tt
3
4
Digital Frequency Agile Dual Channel Wireless Microphone System
The GXLD2QM™ Digital frequency agile wireless system includes the following features:
GXLD2QM Wireless Specifications:
Frequency Response 20Hz –20kHz
Modulation High Definition Digital QPSK
Transmitting Power 10mW
Sensitivity -43 dBV (6.8mV) @ 1Pa
Battery Life >10Hrs
Frequency Band 500Mhz – 599Mhz
Receiver
Transmitter
•Digital High Definition Audio
•Frequency Agile Design
•DualHandheld System
•QuickMic™ connection to your mixing board via integrated ¼” jack
•QuickMic™ is supplied with USBand TRS 3.5mm adapters for added flexibility
•Handheld transmitters feature the CADLive Style Neodymium capsules
•Handheld transmitters and receiver feature low battery indicators
•Handheld transmitters utilize AA Batteries with>8 Hrs of operati
on
•2 Year Warranty
5
5. Low battery indicator, Blue on, Red needs charged
Power
USB 5V
6. RF indicator, Red Ch A, Green Ch B
6
©2020 CAD Audio Part No. 47830-59-00 PG1 Dec 2020
Adapters
USB adapter
3.5mm TRS adapter
