1
PL-Series
D1301/D1302/D1303/D1304/D1305
D1301
PL- 07
Frequency Diagram
Type: Dynamic, Moving coil.
Freq. response: 40 to 16.500 Hz
Polar Pattern: Cardioid
Sensitivity (1000 Hz): 1,7 mV/Pa*
(*1 Pa = 94 dB SPL)
Max. SPL: 137 dB
Impedance: 600 Ohm
Power supply: none
Connector: 3p. XLR (male-type)
Dimensions: Ø 32 mm x L 157 mm
Net. Weight: 0,245 kg
D1302
PL-ß 07
Frequency Diagram
Type: Dynamic, moving coil.
Freq. response: 50 to 16,000 Hz
Polar Pattern: Cardioid
Sensitivity (1000 Hz): 2,6 mV/Pa*
(*1 Pa = 94 dB SPL)
Max. SPL: 137 dB
Impedance: 600 Ohm
Power supply: none
Connector: 3p. XLR (male-type)
Dimensions: Ø 42 mm x L 160 mm
Net. Weight: 0,271 kg
D1303
PL- 08
Frequency Diagram
Type: Dynamic, moving coil.
Freq. response: 50 to 16.500 Hz
Polar Pattern: Cardioid
Sensitivity (1000 Hz): 1,8 mV/Pa*
(*1 Pa = 94 dB SPL)
Max. SPL: 137 dB
Impedance: 600 Ohm
Power supply: none
Connector: 3p. XLR (male-type)
Dimensions: Ø 51 mm x L 160 mm
Net. Weight: 0,315 kg
D1304
Frequency Diagram
Type: Dynamic, Moving coil.
Freq. response: 50 to 16.500 Hz
Polar Pattern: Cardioid
Sensitivity (1000 Hz): 1,8 mV/Pa*
(*1 Pa = 94 dB SPL)
Max. SPL: 137 dB
Impedance: 600 Ohm
Power supply: none
Connector: 3p. XLR (male-type)
Dimensions: Ø 51 mm x L 160 mm
Net. Weight: 0,298 kg
D1305
PL-08ß
Frequency Diagram
Type: Dynamic, moving coil.
Freq. response: 50 to 16.000 Hz
Polar Pattern: Cardioid
Sensitivity (1000 Hz): 2,9 mV/Pa*
(*1 Pa = 94 dB SPL)
Max. SPL: 137 dB
Impedance: 600 Ohm
Power supply: none
Connector: 3p. XLR (male-type)
Dimensions: Ø 51 mm x L 160 mm
Net. Weight: 0,28 kg
Produktspecifikationer
| Varumärke: | DAP Audio |
| Kategori: | mikrofon |
| Modell: | PL-07 |
