CUEPIX STRIP WW™
SKU# CUE277
Th ri is lumine n IX ew CUEP St p ™ WW a bar ai with re
(5) d dual Wa W 3, K COB L sin ivi 30W rm hite 200 ED
pr ucod ing a 60° beam angle. F es eatur in luc de in ivid dual
pixel control, strobe and zone chase effects, selectable
d curves, DMX and RDM (Rem ce imming ote Devi
Man ment) rt, X and age suppo 3/5pin LR power
in/out connections, (4) button LCD menu display control,
123W max power consumption, an and a multi-voltage
univ hinersal to witc au s g su ly ( v).power pp 100-240
FEATURES
60° Beam Angle 3,200K Bar Luminaire
(5) Pixel Controlled 30W Warm White COB LEDs
Strobe and Zone Chase Effects
Selectable Dimming Curve Effects
DMX and RDM (Remote Device Management) Support
Flicker Free Operation for Broadcast TV and FILM
Integrated Rigging Bracket
Optional 15° Lens Kit Available
Specifications are subject to change without notice ©Elation Professional 07/15
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
ELATION I CUEP ™ IX STRI WWP I Pr u ifi io Sh tod ct Spec cat n ee
Optional 15° Lens Kit
SOURCE
(5) 30W Warm White 3,200K COB LEDs
100,000 Hour Average Lamp Life
PHOTOMETRIC DATA ( Full ON)60°
2,990 LUX 278 FC @3.3’ (1m)
813 LUX 76 FC @6.6’ (2m)
500 LUX 46 FC @9.8’ (3m)
230 LUX 21 FC @13.1’ (4m)
148 LUX 14 FC @16.4’ (5m)
EFFECTS
Individual Pixel Control
Strobe and Zone Chase Effects
Selectable Dimming Curves
COLOR
Warm White 3,200K
CONTROL / CONNECTIONS
(6) DMX Channel Modes (1 / 2 / 5 / 6 / 8 / 10)
RDM (Remote Device Management)
4 Button Touch Control Panel
3pin/5pin DMX In/Out
Power In/Out
SIZE / WEIGHT
Length: 21.6” (550mm)
Width: 6.4” (161.2mm)
Vertical Height: 6.8” (172.5mm)
Weight: 13.9 lbs. (6.3 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
123W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
APPR ALS / RATINGSOV
CE | cETLus | IP20
INSTALLATION
Rigging: Clamps (Not Included)
Working Position: Any (360°)
INCLUDED ITEMS
(1) Power Cable
sp atecific ions
I
ELA CUEP ™ TION IX STRI WWP
I
www.elationlighting.com
Specifications are subject to change without notice ©Elation Professional 07/15
Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040
323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com
Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, Netherlands
+31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu
DI L IAGR SMEN ONASI D AM
PR A SODUCT SPECIFIC TION
PHOT D AOMETRIC AT
OP ONA ESSOTI L ACC RIES
ORDER CODE ITEM
CUE283/15LK CUEPIX Stip TRI & WW 15 Degree Lens Kit
TRIGGER CLAMP Heavy Duty Wrap Around Hook Style Clamp
EWDMXSYSTEM Wireless DMX System (1 Transmitter, 1 Receiver)
PLC3 3’ (1m) PRO Link Cable
AC3PDMX5PRO 5 ft. (1.5m) 3pin PRO DMX Cable
AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable
Additional cable lengths available
80° Field
1m
2m
3m
4m
5m
60° Beam
1 m 3.3 ft 2 m 6.6 ft 3 m 9.8 ft 4 m 13.1 ft 5 m 16.4 ft
60° Beam
Diameter
1.7 5.6 2.4 7.9 3.5 11.5 4.6 15.1 5.8 19.0
80° Field
Diameter
2.2 7.2 3.4 11.2 5 16.4 6.7 22.0 8.4 27.6
lux fc lux fc lux fc lux fc lux fc
FULL ON
2,990 278 813 76 500 46 230 21 148 14
550mm
361mm
110mm
(21.6in)
(14.2in)
(4.3in)
161,2mm
172,5mm
152,2mm
127,5mm
(6.0in)
(6.4in)
(5.0in)
(6.8in)
