Interactive TV Arm: 45-296-026
User's Guide
Guía del usuario
Manuel de l’utilisateur
Benutzerhandbuch
Gebruikersgids
Guida per l’utente
Användarguide
ユーザーガイド
用户指南
사용자 안내서
CAUTION!
MAXIMUM SCREEN SIZE
CAUTION!
MAXIMUM WEIGHT CAPACITY
40 LBS
18.1 KG
60”
888-45-221-W-00rev.C • 11/11
2 of 18
4x
8x
8x
1x1x 1x
4x
8x
8x
1x1x 1x
4x
4x
4x
4x
4x
4x
4x
4x
4x
4x
4x
4x
4x
4x
CONTENTS
Part Quantity Description
1 1 Wall Plate
2 1 Arm/Wall Plate Hardware
3 2 Wall Plate Covers
4 1 Rear Arm Cover
5 1 CFT Arm
6 1 200x200 VESA Monitor Plate
7 4 Spider Adapters
1
2
3
4
5
6
7
P-F
P-D
P-E
P-L
8x
8x
1x1x 1x
4x
P-J
P-K
Wall Kit ST8x2 697-641-00
Part Quantity Description
W-A 2 Lag Bolt
W-B 2 Round Washers
W-C 2 Wall Anchor
4x
4x
Specialty Hardware kit 697-640-00
Part Quantity Description
P-A 1 Philips Screw
P-B 4 Round Head Screws
P-C 8 Nuts
Screws/Hardware For Flat Panel 697-613-00
Part Quantity Description
M-A 4 Philips screws M4 x 15mm
M-B 4 Philips screws M4 x 30mm
M-C 4 Philips screws M5 x 15mm
M-D 4 Philips screws M5 x 30mm
M-E 4 Philips screws M6 x 15mm
M-F 4 Philips screws M6 x 30mm
M-G 4 Philips screws M8 x 15mm
M-H 4 Philips screws M8 x 30mm
M-I 4 Round spacers M6-M8 x 5mm
M-J 4 Round spacers M6-M8 x 10mm
M-K 4 Round washers M4-M5
M-L 4 Round washers M6-M8
P-I
P-H
P-G
P-M
