USER GUIDE
Video Borescope
Model BR100
BR100-en-US_V2.5 11/14
2
Introduction
Congratulations on your purchase of this Extech BR100 Video Borescope. This instrument was
designed for use as an inspection device. It can be used to peer into tight spots and then supply real-
time video and images. Typical applications include ive inspection, cable HVAC inspection, automot
routing, and automotive/boat/aircraft inspection. This meter is shipped fully tested and, with proper
use, will provide years of reliable service. Please visit the Extech Instruments website
(www.extech.com) to check for the latest version of this User Guide.
BR100-en-US_V2.5 11/14
3
Description
1 Display
2 Handle/Battery compartment
3 Power On/Off, Dimmer
4 Flexible tube
5 Camera head and LED’s
1 Power indicator
2 Display On/OFF
3 Power On/Off (side)
4 Image orientation
5 Brightness
6 Contrast
7 Video output
8 Handle connector (rear)
Safety
Do not expose instrument to moisture
Shut off the instrument when not in use
Remove the batteries when cleaning the instrument
Replace all batteries at the same time
1
2
3
4
5
1
2
3
4
5
6
7
8
BR100-en-US_V2.5 11/14
4
Installation
Install the batteries into the instrument body, charge the monitor battery, connect the camera and
flexible tube to the body, and install any accessory as needed.
Battery Installation
1. Remove the screw and cover from the base of the handle.
2. Slide out the battery compartment.
3. Replace the four AA batteries observing polarity
4. Reinstall the battery compartment, cover and screw.
Connect the camera and flexible tube
Connect the camera tube to the instrument body; ensure that the keyed ends are properly aligned.
Once aligned, tighten the knurled knob to hold the connection firmly in place.
Warning. Permanent damage to the flex tube and loss of operation will occur if the flex
tube is subjected to narrow radius or sharp angle bends.
BR100-en-US_V2.5 11/14
5
Attaching the Monitor to the instrument body
Insert the connector on the handle into the opening of the
connector on the monitor and slide down until the monitor is
firmly attached.
Installing the accessory tools
The included accessories (mirror, hook and magnet) all attach to the camera in the same manner.
Refer to the diagrams below:
1. Align the tool as shown in the diagram
2. Wrap the strap latch around the head and snap into place.
Video Output
Insert the video cable into the VIDEO OUT socket on the monitor. Insert the other end of the
cable into the VIDEO IN jack of a TV or other monitor. The LCD Monitor will output a high
quality video image.
Battery Replacement
When the battery icon appears on the LCD, the 'AA' battery must be replaced.
The battery compartment is located on the bottom of the meter.
1. Press in and down on the arrow located above the tilt stand hinge.
2. Replace the 9V battery.
3. Replace the battery cover.
Battery Safety Reminders
Please dispose of batteries responsibly; always observe local, state, and federal regulations
with regard to battery disposal.
Never dispose of batteries in a fire. Batteries may explode or leak.
Never mix battery types. Always install new batteries of the same type.
BR100-en-US_V2.5 11/14
6
Operation
1. Rotate the ON/OFF dial switch to power the camera. The power indicator on the top of the
handle will switch on.
2. Further rotation of the switch adjusts the intensity of the two LEDs on the camera head.
3. Slide the On/Off switch on the side of the monitor to the ON position
4. Press the power button on the face of the monitor. The power light will turn on and the picture
will appear.
5. Press the orientation button on the face of the monitor to rotate the picture as needed.
6. Press the brightness and contrast buttons in conjunction with the rotating the LED intensity for
the best image quality.
7. The tube can be easily maneuvered into position. The tube can be bent into the shape of the
area to be examined.
8. Use the supplied accessories to help retrieve small items.
Charging the Meter
1. Place batteries into the handle of the meter.
2. Attach the monitor to the handle and slide the ON/OFF switch on the side of the meter to
OFF.
3. Rotate the ON/OFF dial to power the camera. The power indicator on the top of the handle
will switch ON.
4. The battery power from the handle will charge the monitor.
5. To save battery power: while charging the meter, remove the cable from the handle. This
prevents the LEDs from lighting and consuming additional power.
Specifications
CAMERA
Imaging Sensor CMOS
Total Pixels 712×486 (NTSC)
Horizontal View Angle 50 degree
Transmission Frequency 2468MHz
Minimum Illumination 0 Lux
Power Supply 4 x AA batteries
LCD Screen Type 2.36” TFT-LCD
Effective Pixels 480 x 234
Video Output Level 0.9-1.3VP-P@75Ώ
Receiving Sensitivity ≤-85dBm
Dimensions (Monitor) (W x D x H) 3.9 x 2.8 x 1.2” (100 x 70 x 30mm)
Operating Humidity (Max.) 15~85%RH
Waterproof Capacity IP67 (imager head only)
Dimensions (Handle) (W x D x H) 7.3 x 5.7 x 1.6” (186 x 145 x 41mm) (Excluding
Flexible Tube)
Weight (approx) 15.5 oz. (440g)
Camera head Diameter 0.67” (17mm)
Operating Temperature +14°F~+122°F (-10°C~+50°C)
BR100-en-US_V2.5 11/14
7
Warranty
FLIRSystems,Inc.warrantsthisExtechInstrumentsbranddevice to be parts andfreeofdefectsin workmanshipforoneyear
fromdateofshipment six(a monthlimited warranty applies to sensors and cables). If it should become necessary toreturnthe
instrumentforserviceduringorbeyondthewarranty period, contact the Customer Service Departmentforauthorization.Visit
thewebsite contactwww.extech.comfor information. A ReturnAuthorization(RA)numbermust be issued before any product is
returned.Thesenderisresponsiblefor shipping charges,freight,insuranceandproperpackagingtopreventdamageintransit.
Thiswarrantydoes not applytodefects fromresulting actionoftheusersuchasmisuse,improperwiring, outsideoperation of
specification,impropermaintenanceor orrepair, unauthorizedmodification.FLIRSystems,Inc.specificallydisclaimsanyimplied
warrantiesor ormerchantability fitnessfor a specificpurposeand be anywillnot liablefor direct, indirect, incidental or
consequentialdamages.FLIR’stotalliabilityislimitedtorepairor ofreplacement the product. The warranty set forth above is
inclusiveand no otherwarranty,whether written ororal,isexpressedorimplied.
Calibration, CustomerRepair,and CareServices
FLIRSystems,Inc.offersrepairandcalibrationservices for the Extech Instruments products we
sell.NIST Customercertificationformostproductsisalsoprovided.Callthe ServiceDepartmentfor
information product.oncalibrationservicesavailableforthis Annualcalibrationsshouldbe
performedtoverifymeter generalperformanceand andaccuracy.Technicalsupport customer
service theisalsoprovided,referto contactinformationprovidedbelow.
Copyright ©2014FLIRSystems,Inc.
Allrightsreserved rightincludingthe of orreproductioninwhole in inpart anyform
www.extech.com
SupportLines:U.S.(877) (603)439 8324;‐ International:+1 324 7800‐
Technical Support: Option3; ‐E mail: support@extech.com
Repair & Returns:Option4; repair@extech.com ‐E mail:
Productspecificationsaresubjectto noticechangewithout
Pleasevisitourwebsiteforthemostup‐ ‐to dateinformation
www.extech.com
FLIR TownsendCommercialSystems,Inc., 9West,Nashua,NH03063USA
ISO9001Certified
