Sida 1/7
1
C900 SERIES
SMART WI-FI PROGRAMMABLE THERMOSTAT,
BATTERY-POWERED
PROGRAMMABLE THERMOSTATS,
THERMOSTATS,
AND TEMPERATURE CONTROL SYSTEMS
■Suitable for controlling heating and/or
cooling systems
■Remote control via smartphone app
■SMART features for an innovative approach
to home comfort
■Also ideal for controlling hydronic
systems by regulating based on perceived
temperature
Power supply 2 AA 1.5V alkaline batteries
230 V - 50 Hz (via C800AL power adapter)
Contact rating 5(3)A 250 Vca
WiFi connection 2,4 GHz (802.11 b/g/n)
Temperature adjustment range 2 ÷ 40 °C, increase 0,1°C
Differential adjustment STD, 0,3 ÷ 5 K
Reference thermal gradient 4 K/h
Ambient relative humidity display range 0 ÷ 99 %, increase 1 %
C900Q Smart Wi-Fi programmable thermostat, battery-powered, white
C900QN Smart Wi-Fi programmable thermostat, battery-powered, black
C900QS Smart Wi-Fi programmable thermostat, battery-powered, sand
C900R Smart Wi-Fi programmable thermostat, battery-powered, white
C900RN Smart Wi-Fi programmable thermostat, battery-powered, black
C900RS Smart Wi-Fi programmable thermostat, battery-powered, sand
C800AL Power supply kit 230Vca/3.3Vcc for C900 and C800 series (flush mounting)
MODELS
■C900Q_ ■C900R_
2
C900 SERIES - SMART WI-FI PROGRAMMABLE THERMOSTAT
INSTALLATION
■C900Q_: Wall-mounted or flush-mounted in 500 or 502-type wall
boxes, at approximately 1.5 m from the floor, in a suitable position to
correctly detect the room temperature
■C900Q_ ■C900R_
■C900R_: Wall-mounted or flush-mounted in 503-type wall boxes,
at approximately 1.5 m from the floor, in a suitable position to
correctly detect the room temperature
The C800AL flush-mounted power supply kit (230 V AC / 3.3 V DC) is available in the catalogue and is compatible with both C800 and C900
Series devices.
STANDARDS AND CERTIFICATIONS
■Compliant with EN 60730-1 and related parts
■Directive 2014/53/UE (RED); 2014/30/UE (EMC); 2014/35/UE (LVD)
■ErP Classification (EU Reg. 811/2013 - 813/2013): Class IV, efficiency 2%
DIMENSIONS (mm)
98
98
20
98
20
125
3
C900 SERIES - SMART WI-FI PROGRAMMABLE THERMOSTAT
ELECTRICAL SPECIFICATIONS
Power supply 2 AA 1.5V alkaline batteries
230 V - 50 Hz (via C800AL power adapter)
Maximum power consumption 5 W
Contact rating 5(3)A 250 Vca
Action type 1 B.U. (Micro disconnession)
Output type
1 relay for heating/cooling (3 screw terminals, normally closed +
normally open)
Software class A
Electrical insulation Double insulation
Impulse voltage 4000V
■ELECTRICAL CONNECTIONS
Connection Example
1: Common
4: Normally Open (NO)
2: Normally Closed (NC)
Power supply 3.3 VDC
(only from C800AL)
1 4 2
Connect terminals 1 and 4 to the system.
+ -
