2
Electronic programmable thermostat with weekly programming, to control heating and air-conditioning
installations.
Plate not included in the package.
Temperature
regulation
range
Differential*
Temperature
displayed
range
Adjustable
antifreeze
temperature
range
Power supplyContacts
rating
CH141E2 ÷ 40 °C0,25 K-35 ÷ 60 °C0 ÷ 7 °C2 batteries AAA 1,5V5(3)A 250Vca
CH143E2 ÷ 40 °C0,25 K-35 ÷ 60 °C0 ÷ 7 °C230V 50Hz5(3)A 250Vca
58
68
52
Dimensions (mm)
* Differential values are referred to a thermal gradient of 4K/h.
ELECTRICAL FEATURES
Software class A.
Type of action: 1BU (micro disconnection)
Voltage-free switching contact.
As the temperature increases, the thermostat opens contact 1-2 and closes contact 1-4.
4 2 1
HOMOLOGATION AND STANDARDS
Complies with EN 60730-2-9 standards.
ErP Class IV; 2% (Reg. EU 811/2013 - 813/2013)
Intellicomfort CH141E-CH143E
Flush mounting weekly programmable thermostat,
battery operated and 230V
Compatible with most common plates on the market, thanks to the multiplate frame.
“MULTIPLATE” FRAME
Plate not included in the package.
