Sida 1/6
1
INTELLICOMFORT CH180WIFIRL
WIFI WIRELESS MULTI-ZONE
PROGRAMMABLE THERMOSTAT
PROGRAMMABLE THERMOSTATS,
THERMOSTATS
AND TEMPERATURE REGULATION
■Supervisor for the Fantini Cosmi wireless multi-
zone temperature and humidity control system
■Long-range LoRa
®
radio communication
■Weekly and seasonal programs
■Control of heating, cooling, and
dehumidification systems
■Remote control via mobile APP
Temperature setting range 2 ÷ 30°C, 0.1°C increasing
Relative humidity setting range 30 ÷ 70%, 1% increasing
Power supply 230V 50 Hz
Contact rating 5(3)A 250 V AC
WiFi connection 2.4 GHz (802.11 b/g/n)
Transmission frequency ISM band EU868
Control differential 0.3 ÷ 5 K
STANDARDS AND CERTIFICATIONS
■Compliant with EN 60730-1 and relevant parts
■Compliant with Directive 2014/53/EU (RED)
■ErP classification (EU Regulation 811/2013 –
813/2013):
■Class IV; Energy efficiency contribution: 2%
■Class VIII; Energy efficiency contribution: 5%
when used with other devices in the Fantini
Cosmi wireless multi-zone system
DIMENSIONS mm
127
82
24
2
CH180WIFIRL - WIFI WIRELESS MULTI-ZONE PROGRAMMABLE THERMOSTAT
ELECTRICAL CHARACTERISTICS
Power supply 230V-50Hz
Maximum power consumption 5 W
Contact rating 5(3)A 250 VAC
Type of action 1 B.U. (Micro-disconnection)
Output relay configuration
■■ 1 relay for heating/cooling or dehumidifier (3 screw
terminals, normally closed + normally open)
Software CLASS A
Electrical insulation Double insulation
■ELECTRICAL CONNECTION
INSTALLATION
Wall mounting, or installation on standard 500, 502, or 503 wall boxes, at a height of approximately 1.5 m from
the floor, preferably on interior walls and away from doors and windows.
WIRING EXAMPLE
Connection to the system:
terminals 1-2
Power supply 230V
L-N
3
CH180WIFIRL - WIFI WIRELESS MULTI-ZONE PROGRAMMABLE THERMOSTAT
GENERAL CHARACTERISTICS
WiFi connection 2.4 GHz (802.11 b/g/n)
Transmission frequency ISM band EU868
Temperature setpoint range 2 ÷ 30 °C, 0.1°C increasing
Room temperature measurement/display range -50 ÷ +50 °C
Maximum ambient temperature 45°C
Relative humidity setpoint range 30 ÷ 70%, 1% increasing
Ambient relative humidity measurement/display range 0 ÷ 100%
Control differential 0.3 ÷ 5 K
Radio modulation LoRa
®
Storage temperature 10°C ÷ +60°C
Protection rating IP40
Pollution degree 2
Available display languages Italian, English, French, Spanish, German, Russian
CH180WIFIRL screen lock With password and cleaning mode
System management ■Up to 8 zones
■Up to 32 devices connected directly
■Daylight saving time
■Summer/Winter mode
■Display of system usage in operating hours
■Display of system faults
■Temperature offset correction for thermostats
