Sida 1/4

LLE

EED V

D V

D VD Vi

iid

dde

eeo L

o L

o Lo Li

iig

ggh

hht

型号: LED 36

Instruction manual | 说明手册

Chinese English Bilingual | 中英文双语

感谢您购买神牛产品！

LED36摄影灯非常适用于微距拍摄、静物拍摄、以及视频拍摄等。由

36颗高亮度LED灯珠组合，发光强度大、色温准确、小巧机身、便携无忧。

手动调节亮度旋钮可以控制发光的亮度，在实际拍摄中可根据实际需要，灵

活拼接，多灯组合实现不同的光线亮度。

一、前言

01. 36粒灯珠

02. 电源开关

03. 亮度旋钮

04. 电池仓

05. 热靴接口

06. 固定旋钮A

07. 固定旋钮B

08. 热靴连接座

09. 1/4″支架安装孔

三、部件

四、安装使用

1. 安装摄影灯

● 转动摄影灯的固定旋钮A(06)至最高点，固定

摄影灯。转动摄影灯的固定旋钮B(07)至最高

点，将热靴连接座水平插入相机或摄像机热靴。

● 向下扭紧固定旋钮B(07)。

注：如您的摄像机没有相应的热靴座，可以购买市面上的摄像

机连接支架，通过摄影灯上的1/4″支架安装孔来固定。

● 打开电池仓(04)。

2. 使用摄影灯

● 按电池仓里的正负极

标识安装电池(2*AA)，

并关闭好电池仓。

● 打开电源开关(02)，

摄影灯开始发光。

● 通过调节亮度旋钮(03)，可控制发光的亮度。

当使用完之后请关闭电源开关(02)。

3. 摄影灯组合使用

通过热靴接口 (05)与热靴连接座

(08)之间的连接，可以组合多个摄

影灯在一起，加强发光亮度，更好

的控制摄影的光线效果。

电池供电

功率

使用时长

色温

亮度

调光方式

灯珠数量

工作环境温度

产品尺寸

净重

2*AA电池

＜1.3W

>1.5小时(以碱性电池为参考)

55 6500~ 00K

＞0Lux (0.5米)26

无级调光

36个

-10~40度

70*89*38mm

80g

五、产品参数

* 设计和规格如有变更，恕不另行通知。

705-LED360-00

警告

请保持干燥：请勿用湿手接触产品，亦不可将产品浸入水中或暴露于雨中。

请勿私自拆卸产品，如产品出现故障须由本公司或授权的维修人员进行检

查维修。

请勿让儿童接触本产品。

本产品不能防水，在雨天及潮湿环境下请注意防水。

请勿放置在超过度的高温环境中。50

请勿在化学品、可燃性气体或其他特殊物质附近使用闪光灯，这些物质

在特殊情况下可能对闪光灯发出的瞬间强光敏感，有可能导致火灾或电

磁干扰。在这些场合下，请注意相关警告标识。

使用电池的注意事项：

● 切勿将电池投入火中或加热升温。

● 当电量用尽时，电池容易漏液。所以为了避免产品受损，请在长期不

使用本产品或电量用尽时取出电池。

● 如果受损电池中的液体接触到皮肤或衣服，请立即用大量清水冲洗。

LLE

EED V

D V

D VD Vi

iid

dde

eeo L

o L

o Lo Li

iig

ggh

hht

Thank you for purchasing this Godox Product!

LED36 video light is excellent for macrophotography, product shooting, and

video recording, etc. This lightweight and portable light provides high

brightness and accurate color temperature. You can flexibly control the light

brightness by using the dimmer and by interlocking multiple lights.

Foreword:

01. 36 LED Beads

02. Power Switch

03. Brightness Controller

04. Battery Compartment

05. Light Hotshoe Connection

06. Locking Ring A

07. Locking Ring B

08. Camera Hotshoe Connection

09. 1/4″ Bracket Mounting Hole

Parts:

Installation and Operation

1.Installing the Video Light

Screw the Locking Ring A (06) and B (07) to the

highest point so that the light is fixed and insert the

Camera Hotshoe Connection horizontally into the

hotshoe of a camera or a camcorder.

Tighten the Locking Ring B (07).

Open the Battery

Compartment (04).

2.Using the Video Light

Install batteries (2*AA)

according to indications

in the compartment and

then close it.

Switch the power on,

the video light giving

out light.

Turn the Brightness Controller (03) to adjust the

brightness.

Turn the power off if it will not be used.

3.Interlocking Multiple Video Lights

Through the Light Hotshoe Connection

(05) and Camera Hotshoe Connection

(08), multiple video lights can be

interlocked together to strengthen the

lighting brightness and get a better

control of the lighting effects.

Battery

Power

Duration

Color Temperature

Brightness

Brightness Control

LED Beads Quantity

Operation Temperature

Dimension

Net weight

Technical Data:

* Product design and specifications are subject to change without notice.

Note: If your camcorder has no hotshoe connection, you are advised to purchase a

connecting bracket for camcorder. The video light has a 1/4″ Bracket Mounting Hole as

your camcorder does. Therefore, you can easily connect both the light and the

camcorder to the bracket.

Model: LED 36

Instruction manual | 说明手册

Chinese English Bilingual | 中英文双语

Two AA batteries

<1.3W

Approx. 1.5 hours with alkaline batteries

5500~6500K

>260Lux (0.5m)

Stepless

-10~40℃

70*89*38mm

80g

Always keep this product dry. Do not use in rain or in damp conditions.

Do not disassemble. Should repairs become necessary, this product must

be sent to an authorized maintenance center.

Keep out of reach of children.

As this product do not have waterproof function, please take measures of

waterproof in rainy or damp environment.

Do not use or store the product if the ambient temperature reads over 50°C.

Do not use the flash unit in the presence of flammable gases, chemicals and

other similar materials. In certain circumstance, these materials may be

sensitive to the strong light emitting from this flash unit and fire or

electromagnetic interference may result.

Observe precautions when handling batteries

● Do not put batteries into a fire or apply direct heat to them.

● Batteries are prone to leakage when fully discharged. To avoid

damage to the product, be sure to remove batteries when the

product is not used for a long time or when batteries run out of

charge.

● Should liquid from the batteries come into contact with skin or

clothing, rinse immediately with fresh water.

Warning:
