E39.0.01.6C-01
Operating manual
for
T-Logg 100
Version 1.0
1 General
The Logger T-Logg 100 is designed as a cost-efficient solution for monitoring temperatures. It enables an individual
programming of the recording time. The last 16,000 measuring values can be stored in the memory. In addition, the
LCD-display indicates both the temperature measured at the moment and the operating status of the logger.
2 Required accessory:
The USB interface of your PC is used to program, start and read out the T-Logg 100.
For this following accessory is required:
Level converter USB 100 or USB 100 SL for direct connection to the USB port of the PC,
cable length approx. 1m.
MINISOFT software (version 7.11 or later / free of charge) to start the logger and read out the logger data.
Notice! It’s also possible to use the T-Logg 100 with the comprehensive software GSOFT 40K
(version 7.11 or later).
GREISINGER electronic GmbH
D - 93128 Regenstauf, Hans-Sachs-Straße 26
Tel.: +49 9402/9383-0, Fax: +49 9402/9383-33, eMail: info@greisinger.de
E39.0.01.6C-01 Operating instruction T-Logg 100 Page 2 of 4
3 Specification:
Measuring range: -25 … +60 °C
Resolution: 0.1°C (display and memory)
Accuracy: < ± 0.5K
Sensor: Integrated in device
Display: LCD display, 10 mm high, 4-digit
Recording interval: 2s to 5h
Measuring value memory: 16,000 values
Memory type:
FILLING MEMORY:
>>
Once the memory is filled with data, the recording will automatically be halted.
RING MEMORY:
>>
The old data will be overwritten in case of memory overflow.
Recording time: Ca. 9 hours up to 9 years, depending on measuring cycle.
Nominal temperature: +25 °C
Working temperature: -25 … +60 °C
Storage temperature: -30 … +85 °C
Battery: CR 2430, exchangeable.
Battery service life: Approx. 2 years (if interval is 15 min.), depending on measuring cycle and operating
temperature.
Interface: Serial interface, 3-pin miniature plug.
Data communication: Via USB interface.
Dimensions / housing: 48.5 x 48.5 x 35.5 mm (H x W x D), plug an fixation flap not included.
Housing made of shock resistant plastic, transparent front made of
polycarbonate, splash water-proof: IP 65.
EMC: The T-Logg 100 have been manufactured in accordance with the regulations
concerning EMC (2004/108/EG).
The device meets EN61326 (appendix A, class B).
Additional error: < 0.5%.
_______________________________________________________________________________________________________________________
GREISINGER electronic GmbH Hans-Sachs-Straße 26 Tel.: +49 9402/9383-0 http://www.greisinger.de
D-93128 Regenstauf Fax:
+49 9402/9383-33 eMail: info@greisinger.de
E39.0.01.6C-01 Operating instruction T-Logg 100 Page 3 of 4
4 Connection
■
Assignment of the input jack
(front view to the pins):
Interface [–]
Not connected
Interface [+]
5 Advice regarding state of logger upon delivery:
Upon its delivery the logger is in a kind of 'sleeping state': The display does not show anything, the power
consumption is at its minimum.
The T-Logg 100 ‘wakes up’ as a communication link with a software has been established. After that the message
‘Stop‘ appears at display. The logger is ready for operation now.
6 Operating mode display:
The T-Logg 100 is equipped with a 10 mm LCD display.
The main purpose of the LCD display is to indicate the temperature. Depending on the operating mode of the
logger, other messages will be displayed as well.
STOP:
The T-Logg 100 is ‘stopped’. No data are recorded. The logger memory is empty.
The logger is reset and can be restarted.
HALT:
The T-Logg 100 has been ‘halted’. The stored data can be read.
The logger memory is not empty.
DISPLAY OF TEMPERATURE:
The small arrow in left-hand corner is flashing The logger is active. Temperature measurements
are carried out at certain intervals. The temperature measured will be stored.
START DELAY:
The logger is active, but no data are recorded. As soon as the start delay time has expired, the
logger will start recording in accordance with the starting conditions programmed before.
START ALARM:
The logger is active, but no data are recorded. Recording will start as soon as the temperature is
within the min. and max. alarm limits.
_______________________________________________________________________________________________________________________
GREISINGER electronic GmbH Hans-Sachs-Straße 26 Tel.: +49 9402/9383-0 http://www.greisinger.de
D-93128 Regenstauf Fax:
+49 9402/9383-33 eMail: info@greisinger.de
