INPUT
GAIN
Bass
+
X
Space
X
3
2
1
0dB 18dB
10. Single-ended 3.5mm input
This is an S-Balanced analogue input.
11. CA logue inputRana
This is an analogue input.
12nalogue int. RCA apu
This is an analogue input.
13. DC 5V power
The ZEN Air CAN must ONLY be powered by 5 volts.
Tip: For best performance, an ultra-low noise power adapter such as the iFi iPower2 or
iPower X is recommended.
Specifications
Power supply requirement:
Max Output:
THD & N:
SNR:
Max. Input:
RCA:
3.5mm:
Gain:
Frequency Response:
Power consumption:
Dimensions:
Net weight:
Wanty rraperiod:
Specications are subject to change without notice.
DC 5V/2.5A (centre +ve)
>6.7V/75 mW (@ 600Ω)
>6.5V/660 mW (@ 64Ω)
>6.2V/1200 mW (@ 32)Ω
0.005% (@ 100 mW/1.27V 16Ω)
>114dBA (@ 6.7V)
3.8V RMS
1.92V RMS
0dB, 9dB and 18dB
10Hz - 100kHz (-3dB)
No Signal ~5W / Max Signal ~13W
158 x117 x35 mm (6.2" x 4.6" x 1.4")
35(0.72g 8 Ibs)
12 months
246
Thank you for purchasing the CAN from ZEN Air series. The
ZEN Air CAN is a single-ended audio amplifier.
1. Power switch
Press to turn on, press again to turn off.
2. Input channel switch
Use the button to choose between the following input options:
Inpu
t 1: Single-ended 3.5mm
Inp
ut 2: RCA
In
put3: RCA
3. Gain selection: 0dB/9dB/18dB
Always start from 0dB and then increase the gain level to attain an
enjoyable and comfortable level of volume from the headphones.
Warning: at the outset do not use excessive gain, otherwise damage to hearing or
connected headphones may ensue. AMR/iFi audio is not responsible for any damage
or injury from misuse.
4. Analogue Volume Control
At normal listening levels, the volume control should be above the 12
o'clock position. Increase the gain level to enjoy a higher listening level.
5. Single-ndede 6.3mm output
For connecting single-ended 6.3mm headphones. With single-ended
3.5mm headphones, connect with a 3.5mm to 6.3mm adapter.
6. S-Balanced 4.4mm output
For connecting 4.4mm headphones.
7. XBass+ LED indicator
XBass+ is uniquely designed to extend bass response to suit
different headphones. It is a purely analogue circuit.
8. XSpace LED indicator
XSpace recreates a holographic sound eld. It is a purely
analogue signal processing circuit designed for listening to
headphones as if one was listening to speakers. This
addresses the 'music inside the head' sensation, which can
make for unsettling listening.
Tip: Sonically-hindering DSP is NOT used for XBass+ and XSpace systems. They use the
highest-quality discrete components and operate purely in the analogue domain. Hence
all the clarity and resolution of the original music is retained.
9. Settings
This button chooses between:
- Off
- XBass+
- XSpace
- XBass+ and XSpace
Ver1.0
ifi-audio.com
19
DC 5V
L
R
1
Technology licensed from AMR-Audio, UK Assembled in China
CAN
Inputs
3
10111213
5378
S-BAL
Air
9dB
L
R
2
