19054 28th Avenue Surrey, BC Canada V3S 6M3

T: 604 538 7162 TF: 1-855 85 KUZCO F: 604 538 7196

W: kuzcolighting.com

20160414

2a.

1a.

1b.

2b.

1e.

3a.

1c.

1d.

INSTALLATION SHEET

EP48224

LED Exterior Pendants

START FROM HERE

•

Make sure power is completely off at the fuse box.

•

Have your fixture installed by a qualified licensed electrician

•

Prepare everything in a clear area.

•

Wear gloves at all times during this installation.

•

Read instructions carefully before you start assembly.

•

Keep this instruction sheet for future reference.

Technical Support: 1-877-452-6858

Please Note:

•All Kuzco LED fixtures come with pre-wired LED module(s).

• Unless instructed to do so, please do not touch any part of the LED module(s) as any

unnecessary contact with the module could cause permanent damage.

• For dimming, an ELV (Electronic Low Voltage) type of dimmer is required.

2d.

Illustration 1

3b.

Caulking

V+

V-

+

-

DC

Driver

Illustration 2

+

-

+

-

V+

V-

You have now completed the installation of your fixture,

enjoy.

You are now ready to mount the canopy to the (2a)

mounting plate connect all wires correctly G (1c). First

ground to ground, N neutral wire (white to white), L live

wire (black to black) with provided marettes from the (1b)

hardware package. Align the holes in the canopy (2a) to

the threaded screws hanging downward from the (1d)

mounting plate . Push the canopy up towards the (1c)(2a)

ceiling so the two screws clears through the hole in (1d)

the canopy . You can now screw on the decorative (2a)

nuts (2b) onto the threaded studs.

Remove the fixture from its original packaging. Remove the

mounting plate from within the canopy by remov(1c)(2a)-

ing the decorative nuts . Secure the mounting plate (2b)

(1c)(1a) to the junction box with the screws (1e) provided

in the hardware package.

1.

3.

Attach the rods to the pendant by threading in (2c)(3a)

clockwise until it is secured. Connect the rods and pendant

to the canopy by threading clockwise. (If the input wires

from the driver are too long, please cut accordingly as

an option). Connect the live (black) and neutal (white)

wires onto the DC Driver Connect all (See Illustration 2).

the glass to the pendant by threading in clockwise. (3b)(3a)

(Do not over tighten.)

2.

To prevent moisture from entering the outlet box and

causing a short, seal around the top perimeter between

the fixture and the surface with weather resistant caulking

(See Illustration 1).

4.

5.
