© LINDY Group - FIRST EDITION (February 2019)
4x2 HDMI 2.0 18G Matrix Switch
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
No. 38084
lindy.com
Tested to comply with
FCC Standards
For Home and Oce Use!
User Manual English
Introduction
Thank you for purchasing the Lindy 4x2 HDMI 2.0 18G Matrix Switch. This product has been designed to
provide trouble free, reliable operation. It benets from both a LINDY 2 year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
This matrix is a high performance solution for distributing content from multiple source devices to two
displays. Supporting HDMI 2.0 18G signals, this matrix allows for the transmission of clear 4K Ultra HD
60Hz resolutions, while additional support for High Dynamic Range ensures video content can be seen
with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for digital signage
displays in retail or hospitality or creating engaging educational setups.
Package Contents
▪ HDMI Matr ix
▪ IR Remote Control and CR 2025 Battery
▪ Multi-country Power Supply (UK, EU, US & AUS) Barrel Size: 5.5/2.1 , mm
▪ 2 x Mounting Brackets
▪ This Manual
Features
▪ HDMI 2.0 18G HDCP 2.2 Compliantbps,
▪ Supports resolutions up to 3840x2160@60Hz 4:4:4 8bit, with HDR support
▪ Supports pass-through HDMI audio up to 7.1CH
▪ Audio extraction from Output A to Toslink (Optical) and 3.5mm Analogue Audio
▪ Automatic downscaling from Output B – 4K to 1080p
▪ EDID Management
▪ Control switching via push buttons on the unit and IR remote
Specication
▪ Input: 4 x HDMI Type A (Female), IR Receiver
▪ Output: 2 x HDMI Type A (Female), 3.5mm Stereo Audio (Female), Toslink Optical (Female)
▪ Metal Housing
▪ Operating Temperature: 0°C - 40°C (32°F - 104°F)
▪ Storage Temperature: -20°C - 60°C (-4°F - 140°F)
▪ Humidity: - 90% RH (non-condensing) 20
▪ Power Requirements: 5VDC 1A
Installation
Please ensure all devices are switched o before making any connections.
Connect the source devices such as a PC, Blu-ray player or games console to the HDMI matrix input ports.
Then connect the high denition displays to the HDMI matrix output ports. When all the connections are
made, connect the power supplies.
Once all the connections have been made, switch on the devices in this order: displays, HDMI Matrix,
source devices. Please allow a few minutes for the devices to handshake and for the signals to appear.
