Sida 1/21

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This is Network Device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up to date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

Technical specifications, brochures and more info about products athttps://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

This Device accepts input of 24V DC power adapter, which is provided in the original packaging of this device.

First steps:

First steps:First steps:

Make sure your ISP is allowing hardware change and will automatically issue an IP address.

Connect your ISP cable to the first Ethernet port.

Connect your PC to any of Ethernet ports.

Connect the device to the power source.

Use a Web browser or WinBox to connect to the default IP address of 192.168.88.1 from any port, with the username and no password.

admin

If IP is not available, download WinBox from our webpage and use it to connect through MAC address.

Update RouterOS software to the latest version, make sure that the device has an internet connection.

If the device does not have an internet connection update software by downloading the latest version from our webpagehttps://mikrotik.com/download

Find the latest software and choose your packages.

To get architecture type of your device model, open WinBox, WebFig go to (System/Resources).

Download packages to the PC and upload them to the WinBox, WebFig, (Files) menu and reboot the device.

Set up your password to secure the device.

For RBFTC11 models, connect Ethernet cable to the port and SFP cable to SFP port. The device is a simple Fiber to Copper converter.

For LHGR and SXTR models, please install your own modem and insert a valid SIM card into the slot.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation to people and damage to the system.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures.

Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.

BG - Български. Бързо ръководство

BG - Български. Бързо ръководствоBG - Български. Бързо ръководство:



.Това е мрежово устройство Можете да намерите името на модела на продукта на етикета на регистъра (ID).

Моля, посетете страницата с ръководството за потребителя на за пълното актуализирано ръководство за употреба.https://mt.lv/um-bg

Или сканирайте QR кода с мобилния си телефон.

Технически спецификации, брошури и повече информация за продуктите наhttps://mikrotik.com/products

Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg

Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете консултант https://mikrotik.com

/consultants

Това устройство приема вход на 24V DC адаптер за захранване, който се предлага в оригиналната опаковка на това устройство.

Първи стъпки:

Първи стъпки:Първи стъпки:

Уверете се, че вашият интернет доставчик позволява промяна на хардуера и автоматично ще издава IP адрес.

Свържете вашия ISP кабел към първия Ethernet порт.

This device needs to be upgraded to RouterOS v6.46 or the latest version to ensure compliance with local authority regulations!

It is the end users responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must beprofessionally installed

Това устройство трябва да бъде надстроено до RouterOS v6.46 или най-новата версия, за да се гарантира спазването на местните

регулаторни разпоредби.

Крайните потребители са отговорни за спазването на местните разпоредби, включително работата в рамките на законни честотни канали,



извеждане на продукцияизисквания за захранване, окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства

на MikroTik трябва да бъдатпрофесионално инсталиран.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	brytare
Modell:	CRS318-16P-2S+OUT
Bredd:	212 mm
Djup:	78 mm
Höjd:	303 mm
Processorfrekvens:	800 MHz
Strömförbrukning (max):	316 W
Certifiering:	CE/RED, EAC, RoHS
Internminne:	256 MB
Processor:	98DX226S
Rackmontering:	Nej
Flashminne:	16 MB
Strömförsörjning ingår:	Ja
Temperatursensor:	Ja
Produktens färg:	Vit
Inbyggd processor:	Ja
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Temperatur vid drift:	-40 - 70 ° C
Kommunikationsstandarder:	IEEE 802.3af, IEEE 802.3at
Adresstabellstorlek:	- poster
Switch kapacitet:	72 Gbit/s
Hastighet vid vidarebefordran:	53.6 Mpps
10G stöd:	Nej
Antal SFP+-modulplatser:	2
Antal grundläggande RJ-45 Ethernet-portar:	16
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Staplingsbar:	Nej
Switch-lager:	L2/L3
Strömanslutning:	DC-in-uttag
Power over Ethernet (PoE)-portar kvantitet:	16
Likströmsdriftspänning:	18 - 57 V
