Sida 1/2

hEX S

First use

Connect your Internet cable to one of the two ports labeled “Internet”, depending on whether you will use an

SFP module or Ethernet.

Connect your local network computers to ports 2-5 set your computer IP configuration to automatic (DHCP).

The IP address from local network is 192.168.88.1, use it in your browser to access the device.

Powering

The device accepts powering from the power jack or from the first Ethernet port

Direct input power jack (5.5mm outside and 2mm inside, female, pin positive) accepts 12-57 V DC.

The first Ethernet port accepts passive or 802.3af/at Power over Ethernet in the range of 12-57 V DC.

The power consumption of this device under maximum load is up to 11 W.

Booting process

The device is already configured and protected from the internet side. Once your PC is connected to one of the LAN

ports, open http:// 192.168.88.1 in your web browser to start configuration Since there is no password by default, you .

will be logged in automatically. Set up your password in the screen that loads. RouterOS includes many configuration

options in addition to what is described in this document. We suggest to start here to get yourself accustomed to the

possibilities: . http://mt.lv/help

In case IP connection is not available, the Winbox tool (http://mt.lv/winbox) can be used to connect to the MAC

address of the device from the LAN side (all access is blocked from the internet port by default). For recovery

purposes, it is possible boot the device from network, see section Buttons

Extension Slots and Ports

•Five individual 10/100/1000 Gigabit Ethernet ports, supporting automatic cross/straight cable correction (Auto

MDI/X), so you can use either straight or cross-over cables for connecting to other network devices.

•One SFP module cage, supports 1.25G modules.

•MicroSD slot for expanding built in storage.

Buttons

Reset button

Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS

configuration (total 5 seconds).

Keep holding for 5 more seconds, LED turns solid, release now to turn on CAP mode. The device will now

look for a CAPsMAN server (total 10 seconds).

Or Keep holding the button for 5 more seconds until until LED turns off, then release it to make the

RouterBOARD look for Netinstall servers (total 15 seconds).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed

before power is applied to the device. Useful for RouterBOOT debugging and recovery.

Mode button

The action of the mode buttons can be configured from RouterOS software to execute any user supplied RouterOS

script. You can also disable this button. The mode button can be configured in RouterOS menu /system

routerboard mode-button

For more information see www.mikrotik.com or contact Document #37569. Modified on 26.09.17support@mikrotik.com

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Router
Modell:	RB750GR3
Bredd:	113 mm
Djup:	89 mm
Höjd:	28 mm
LED-indikatorer:	Energiljus
Processorfrekvens:	880 MHz
Intern lagringskapacitet:	0.16 GB
Internminne:	256 MB
Processorarkitektur:	MIPS64
Kabelteknik:	10/100/1000Base-T(X)
USB-laddningsport:	Ja
Ethernet WAN:	Ja
Produktens färg:	Turquoise, White
Antal USB-portar:	1
Inbyggd processor:	Ja
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	5
Temperatur vid drift:	-30 - 70 ° C
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	DC
Processorkärnor:	4
Harmonized System (HS)-kod:	85176990
Ingående ström:	8 - 30 A
