Sida 1/5

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This Quick Guide covers the model: RB5009UG+S+IN.

This is a Network Device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

First steps:

First steps:First steps:

Make sure your ISP is allowing hardware change and will automatically issue an IP address.

Connect your ISP cable to the first Ethernet port.

Connect your PC to any of the Ethernet ports.

Connect the device to the power source.

Use a Web browser or WinBox to connect to the default IP address of 192.168.88.1 from any port, with the username admin and there is no password (or, for

some models, check user and wireless passwords on the sticker).

If IP is not available, download WinBox from our webpage and use it to connect through MAC address.

Update RouterOS software to the latest version, make sure that the device has an internet connection.

If the device does not have an internet connection update software by downloading the latest version from our webpagehttps://mikrotik.com/download

Find the latest software and choose your packages.

To get the architecture type of your device model, open WinBox, WebFig go to (System/Resources).

Download packages to the PC and upload them to the WinBox, WebFig, (Files) menu, and reboot the device.

Set up your password to secure the device.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

The socket-outlet shall be installed near the equipment and shall be easily accessible.

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

To avoid contamination of the environment, separate the device from household waste and dispose of it in a safe manner, for example, in designated areas.

Become familiar with procedures for properly transporting the equipment to designated collection points in your area.

Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.

This device needs to be upgraded to v7.10 or the latest software version to ensure compliance with local authority regulations!

It is the end users' responsibility to follow local country regulations. All MikroTik devices must be professionally installed.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Router
Modell:	RB5009UG+S+IN
Certifiering:	CE, EAC, ROHS
USB-version:	3.2 Gen 1 (3.1 Gen 1)
Ethernet WAN:	Ja
Medeltid mellan fel (MTBF):	200000 h
Produktens färg:	Svart
Antal USB-portar:	1
Typ av ethernet-gränssnitt:	2.5 Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	20 W
Temperaturintervall (förvaring):	-40 - 60 ° C
Hållbarhetscertifiering:	RoHS
Likströmsingång:	Ja
Strömkälla av typen:	DC
Mobilt nätverksgeneration:	Stöds inte
Kommunikationsstandarder:	IEEE 802.3af, IEEE 802.3at
Harmonized System (HS)-kod:	85176990
Antal Gigabit Ethernet (koppar)-portar:	7
Power over Ethernet (PoE)-portar kvantitet:	1
Antal installerade SFP+-moduler:	1
