GVIF-JAG

NTV-KIT175

Overview

The GVIF- Kit allows the user to add up to 3 video inputs and a backup camera input to the JAG

factory media screen in select Jaguar vehicles Audio integraon requires that the vehicle have .

a factory audio input.

Kit Contents

AV Input Harness

Power/CAN Harness

GVIF Video cable

GVIF- Interface JAG

Remote

RGB Input cable

Input Toggle Switch

IR Eye Harness

BHM

01/13/13

NTV-DOC166

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

2 | P a g e

Interface Connectors

Dip Switch Sengs* Congure prior to installaon

Dip SW:

Enables

RGB

Enables

Resoluon

adjust

Aermarket

NAV

Factory or

no Rev-Cam

N/A

DOWN

Skips

RGB

Skips

Resoluon

adjust

Factory

NAV

Acvates

aermarket

Rev-Cam

N/A

AV IN/OUT

Power/CAN

Dip Switches

Status LEDs

*Note: If the dip switches are not congured prior to

installaon you must remove power to the unit prior to

making adjustments to the dip switches. When power is

reconnected aer the dip switch adjustment the new

sengs will be stored into memory.

LCD IN/OUT

(LVDS Cable)

Touch

IN/OUT

TX/RX

BHM

01/13/13

NTV-DOC166

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

3 | P a g e

Installaon

1. Locate the factory navigaon drive and gain access to the connectors. The drive usually

can be found in the trunk. Disconnect any connected harnesses to the NAV drive

temporarily .

2. Gather the provided from the GVIF- kit. Connect the ‘Power/CAN Harness’ JAG

following wires to the car:

Note: CAN connecon is not supported at this me. You must connect the GRAY wire

to a reverse lamp for reverse acvaon!

3. Disconnect the factory GVIF cable from the NAV drive, this is a

square, blue connector.

4. Connect the X provided male side (labeled ‘L IN’) of the GVIF video

cable to the NAV drive .

5. Connect the free end (removed in step 3) of the factory GVIF

video cable to the female side of the provided GVIF video cable (labeled ‘LXOUT’).

6. Connect the white end of the GVIF video cable to the interface at the port labeled ‘GVIF

IN/OUT’.

7. Connect the AV Input cable to the port on the GVIF- interface labeled JAG ‘AV IN/OUT’.

If you’re only connecng a reverse camera (and no other

inputs), the signal input from the camera must connect

to the RCA labeled . Refer to the dip-‘REAR-C’

switch sengs chart to skip/enable AV sources

upon toggle switch presses (oponal. Page 2 ).

8. Ad JAGjust dip switches on the GVIF- interface properly, refer to the chart on page 2 for

qualicaons.

9. Connect the white plug from the to the port on the GVIF- ‘Power/CAN Harness’ JAG

interface labeled ‘Power/CAN’.

Interface wires

Connect to car

Black (GND)

Chassis Ground

Red (ACC)

Accessory

Gray (Rear)

Reverse lamp 12v (if adding rear camera)
