ENGLISH
GREAT BRITAIN • CUSTOMER SERVICE
tel. 020 8247 9300 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
36-4550
Ver. 20150520
Trio Spotlight
Art.no 36-6071, 36-6072 Model OCL-563-ALU, OCL-563-WH
Please read theentire instruction manual before using theproduct
and then save it for future reference. We reserve theright for
any errors in text or images and any necessary changes made
to technical data. If you have any questions regarding technical
problems please contact our Customer Services.
Safety
• All light fittings must be installed in accordance with current
safety regulations to prevent life-threatening accidents.
• If you are theleast bit unsure how theinstallation is to be
carried out, contact acompetent electrician.
• The distance from thelight fitting to thenearest wall or
other object must be no less than 50 cm.
• This light fitting is classed IP21 and as such is only suitable
for indoor use. The light fitting may be installed in bathroom
zones 2 and 3 but local regulations must be taken into
consideration. The light fitting must be attached to awater-
impermeable ceiling surface which prevents water from
leaking down and reaching thelight fitting from above.
• The light fitting must under no circumstances be altered
or modified.
• The light bulbs become very hot. Let them cool before
handling them.
Note:
• The light fitting comes without light bulbs. There are several
types of GU10 light bulbs available, such as energy saving
CFL bulbs and LED bulbs.
• There are even simple tools available for simplifying thefitting
and removal of PAR bulbs into this type of light fitting, e.g.
Clas Ohlson article number 36-4550. They grip thePAR
bulbs by means of suction cups, enabling them to be
handled more easily.
• The life of halogen
bulbs can be
prolonged by
avoiding skin contact
with them.
Installation
5. Tighten the retaining knob
clockwise until the light
fitting lies flush and secure
against the ceiling.
6. Fasten thelight fitting to
theceiling bracket using
theincluded screws.
1. Warning! Always
turn off thepower
before beginning
theinstallation.
8. Turn thepower on.
2. Thread the lamp’s eyelet bracket
onto an existing ceiling hook
(orinstall using appropriate parts
and following recommended
fastening methods, if you are
missing an existing hook).
7. Insert your preferred
type of light bulbs.
Max3×35 W, GU10
(sold separately).
3. If the mains lead is surface
mounted onto the ceiling and
must enter the fixture from the
side, first remove the protective
plastic cap from the mains lead
cut-out before threading it in and
connecting it.
4. Connect thewires of theinput
power cable as shown in thefigure.
-The brown or black wire (live
phase) should be connected to
the“L” terminal on thelight fitting.
-The blue wire (neutral) should
be connected to theterminal
marked “N”.
-The green/yellow wire (Earth)
should be connected to the
terminal.
Care and maintenance
Clean thelight fitting by wiping it with alightly moistened cloth.
Only use mild cleaning agents, never solvents or corrosive
chemicals.
Disposal
This product should be disposed of in accordance with local
regulations. If you are unsure how to proceed, contact your
local authority.
Specifications
Power supply 220–240 V AC, 50 Hz
Bulbs Max 3×35 W, GU10 (sold separately)
IP rating IP21
Class I (must be connected to earth)
Finish Brushed steel (36-6071), white (36-6072)
Note: The colour of thewires might not always correspond to
thecolours stated in this manual. If you are unsure, contact
acompetent electrician.
